Page 1: User Manual
User Manual 1/3” HD-TVI Camera, Day&Night, 1920x1080, WDR, 10x AF Zoom, Infrarot, 12/24V TVB-2080Z10IR... -
Page 3: Safety Precaution
FULL-HD AF-ZOOM CAMERA Safety Precaution To prevent fire or shock hazard, do not expose the unit to rain or moisture. To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). - Page 4 FULL-HD AF ZOOM CAMERA Safety Precaution NOTICE The image used in this instruction manual are processed to help comprehension and may differ from actual video of the camera. Avoid installing areas where has shock or vibration which results in the problems. Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
-
Page 5: Table Of Contents
FULL-HD AF ZOOM CAMERA Contents p.03~04 Safety Precaution p.05 Contents p.06~07 Features p.07 Composition p.08 Dimensions p.08 Part Names p.09~11 Installation Instructions p.12~27 Operating Instructions p.28 Specifications... -
Page 6: Features
FULL-HD AF ZOOM CAMERA Features Key Features • Full HD, 2Mega Pixel HD-TVI CAMERA, 1920x1080(30p/25p) • TVI Video Transmission Distance over Coax.; 500M (RG59, 75Ω) • Automatically removable IR Cut filter by Dual filter switcher • Built-in f=5.1~51mm, F1.6~F1.8 Day & Night zoom lens (Optical 10x Auto focus zoom / Digital 32x zoom) •... -
Page 7: General Description
FULL-HD AF ZOOM CAMERA Features General Description This camera realizes the natural and crisp image as you see the scene in front of you by adopting Auto Focus Full HD(1920x1080p) camera module. Highly detailed pictures can be achieved and color reproducibility deserves attention. -
Page 8: Dimensions
FULL-HD AF ZOOM CAMERA Dimensions (unit : mm) 87.30 Part Names SUNSHIELD BOLT POWER SUNSHIELD CABLE OSD Setup CONTROL COVER DUAL WINDOW EASY BRACKET BRACKET FRONT CASE REAR CASE LOCK/UNLOCK SCREW... -
Page 9: Installation Instructions
FULL-HD AF ZOOM CAMERA Installation Instructions 1. Locate the mounting template at the installation position and drill the ceiling or wall if needed. ( *The easy bracket can not be installed on the ceiling) 2. Place the easy bracket on pre-drilled position and fix it through using mounting screws(4x30mm). - Page 10 FULL-HD AF ZOOM CAMERA Installation Instructions Pan & Tilt adjustments • Unlock the screw on the camera bracket through using the torque wrench supplied • Set the camera’s viewing angle then lock the screw on the bracket. 1) Pan limit: Pan is limited to +/- 90°.
-
Page 11: Installation And Commissioning Instructions
FULL-HD AF ZOOM CAMERA Installation Instructions Installation and commissioning Instructions • Make sure the power is removed before the installation. • Follow the order for applying power. First, connect the low voltage (AC24V or DC12V), then plug the AC adapter to AC outlets to avoid an improper reset from power jitter and a damage from the surge voltage when no load. -
Page 12: Operating Instructions
FULL-HD AF ZOOM CAMERA Operating Instructions Using OSD controller Setup menu can be accessed and controlled by OSD control joy stick on the side of camera unit. Five commands are available with the joy stick. The design of OSD could be different according to the Model. Cover Open SUB-OUT OSD Control... - Page 13 FULL-HD AF ZOOM CAMERA Operating Instructions OSD menu Startup Press ‘☟’OSD MENU key down to access the setup menu mode. • EXIT : Exits the setup menu without save. • SAVE : Saves the menu settings. • DFLT : Reset to the factory defaults. •...
- Page 14 FULL-HD AF ZOOM CAMERA Operating Instructions 30/25fps] OFF/ x2, x4 EXPOSURE *60/50fps] OFF/ x2, x4, x8 FLICKERLESS OFF/ON BRIGHTNESS 0~20 BLC/WDR/HLC MID-HIGH, HIGH, LOW, LEVEL MID-LOW,MIDDLE POSITION, SIZE 0~20 LEVEL(0~20), COLOR(0~13) DAY&NIGHT AUTO DELAY 0~255sec THRS 0~28 LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH OFF, ON IR DETECTION...
- Page 15 FULL-HD AF ZOOM CAMERA Operating Instructions COLOR 0~13 OFF/ON PRIVACY INTELLIGENCE TRANS AREA# OFF/ON MOTION MODE OFF, ON SENSITIVITY 0~20 POSITION SIZE 0~255 INTERVAL 0~255 DWELL TIME OFF, ON ZOOM PRESET 10%, 20%, 30% OFF/ON RANGE FILTER LOW, MIDDLE, HIGH AUTO C OFF, HALF, FULL DEFECT...
-
Page 16: Osd Menu Setup
FULL-HD AF ZOOM CAMERA Operating Instructions OSD menu Setup MENU ZOOM/FOCUS ZOOM/FOCUS FOCUS EXPOSURE DISTANCE 1.0m WHITE BAL ZOOM SPEED IMAGE LENS REFRESH ONE PUSH INTELLIGENCE E.ZOOM SPECIAL FUNC ZOOM PRESET DISPLAY HOME POSITION [ EXIT ] [ SAVE ] [ DFLT ] [ BACK ] [ SAVE ]... - Page 17 FULL-HD AF ZOOM CAMERA Operating Instructions 1-5. E. ZOOM (default: OFF) : E-ZOOM is available up to 32x. It starts working when the optical zoom reaches its maximum tele-position. Zoom ratio is displayed on the right bottom corner of the monitor if DISPLAY>DISP SEL>ZOOM RATIO is set to ON. ※...
- Page 18 FULL-HD AF ZOOM CAMERA Operating Instructions 2. EXPOSURE EXPOSURE MODE SHUT SPEED IRIS FLICKERLESS BRIGHTNESS BLC/WDR/HLC DAY&NIGHT EXT-IN [ BACK ] [ SAVE ] [ DFLT ] 2-1. MODE (default: AUTO) : Can set EXPOSURE MODE to AUTO, IRIS P, SHUT. P, and MANUAL. •...
- Page 19 FULL-HD AF ZOOM CAMERA Operating Instructions • 60/50fps (Not Supported) : x8, x4, x2, 1/60(50),1/120(100), 1/250, 1/700, 1/1000, 1/1600, 1/2500, 1/5000, 1/7000, 1/10000, 1/30000sec • 30/25fps : x4, x2, 1/30(25), 1/60(50), 1/120(100), 1/250, 1/700, 1/1000, 1/1600, 1/2500, 1/5000, 1/7000, 1/10000, 1/30000sec 2-4.
- Page 20 FULL-HD AF ZOOM CAMERA Operating Instructions 2-8-2. BLC (Back Light Compensation): : This function is used to brighten an image in the foreground with a highly light area behind it such as sunlight, limiting the affect of silhouette. • POSITION: Adjust the window position •...
- Page 21 FULL-HD AF ZOOM CAMERA Operating Instructions • BURST: It determines whether a color burst signal keeps output or eliminated when camera switches to B/W. If set to ON, B/W video signal contains color burst signal and is compatible with the color equipment but shows the same resolution as color video.
- Page 22 FULL-HD AF ZOOM CAMERA Operating Instructions • ONE PUSH: It is a fixed white balance mode that may be automatically WHITE BAL readjusted only by pressing ‘ONE PUSH’. MODE • MANUAL: This mode allows the white RED GAIN balance to be adjusted manually with BLUE GAIN Red Gan, Blue Gain and Chroma.
- Page 23 FULL-HD AF ZOOM CAMERA Operating Instructions • AUTO: DNR works automatically according to low light conditions. • OFF: Enables DNR function. • LOW/MIDDLE/HIGH: Sets the DNR level. (default: 7) 4-2. MIRROR : Reverses the video signals left, right and/or up, down. •...
- Page 24 FULL-HD AF ZOOM CAMERA Operating Instructions 5. INTELIGENCE PRIVACY INTELIGENCE MASK# PRIVACY MODE MOTION POSITION SIZE COLOR TRANS [ BACK ] [ SAVE ] [ DFLT ] [ BACK ] [ SAVE ] [ DFLT ] 5-1. PRIVACY (default: OFF) : Sets ON/OFF for enabling/disabling PRIVACY.
- Page 25 FULL-HD AF ZOOM CAMERA Operating Instructions • AREA#: Sets 3 areas for the motion detection AREA1~3 to be adjusted. • MODE: Sets OFF/ON for the motion detection area which you selected ‘AREA#’ • SENSITIVITY: Sets the level of motion sensitivity. Setting to low level is more sensitive about motion detection.
- Page 26 FULL-HD AF ZOOM CAMERA Operating Instructions 6-2. IMAGE RANGE : Select image bit range. Setting FULL is 100%, COMP is 75% compressed, or USER is controlling the level from 0 to 32. 6-3. SYSTEM : Sets the composite video signal NTSC(30/60fps) or PAL(25/50fps). 6-4.
- Page 27 FULL-HD AF ZOOM CAMERA Operating Instructions choose a character and ‘☟’selects it. The selected characters are added and displayed on the top left Corner and the cursor moves right automatically for next input. • SPC - Space is inserted when pressed ‘●’ •...
-
Page 28: Specifications
FULL-HD AF ZOOM CAMERA Specifications TVB-2080Z10IR ITEM Imaging Sensor 1/3" Panasonic Progressive Scan CMOS Sensor Effective Pixels 1920(H) x 1080(V) x 25p Scan Frequency 25Hz(V), 18.75Khz(H) Progressive Video Format 16:9, 1080p/25 Video Resolution 1920x1080(1080p/30fps, 25fps), 1280x720p(720p/30fps,25fps) TV System Shutter Speed 1/25~1/30,000sec Sync. - Page 32 High Definition, 2Mega pixel Auto Focus Zoom(x10) IR Bullet Camera eneo® is a registered trademark of VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0...
