Regency F2402M Owners & Installation Manual

Freestanding woodstove
Hide thumbs Also See for F2402M:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation & Owner's Manual
Owners &
Installation
Freestanding Woodstove
Vancouver
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual. For assistance or
additional information consult an authorised installer, service agency or
supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the
vicinity of this or any other appliance.
If you smell gas do not light the appliance.
The appliance and flue system shall be installed in accordance with
AS/NZS 2918 and the appropriate requirements of the relevant building
code or codes.
918-811b
Model: F2402M
Sept-26-2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F2402M and is the answer not in the manual?

Questions and answers

Related Manuals for Regency F2402M

Summary of Contents for Regency F2402M

  • Page 1 Owners & Installation Freestanding Woodstove Vancouver Model: F2402M PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult an authorised installer, service agency or supplier.
  • Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS THE REGENCY FREESTANDING WOOD STOVE MAINTENANCE COMPLIANCE LABEL Maintenance ................16 Copy of Compliance Label ............4 Creosote ................16 - Ways to Prevent & Keep Units Free of Creosote ..16 INSTALLATION Maintenance of Gold Doors ..........16 Glass Maintenance ..............16 Unit Dimensions ..............5...

  • Page 4: Compliance Label

    COMPLIANCE LABEL This is a copy of the label that accompanies each NOTE: Regency units are constantly being Regency Freestanding Woodstove (F2402M). improved. Check the label on the unit and if We have printed a copy of the contents here there is a difference, the label on the unit is the for your review.

  • Page 5: Unit Dimensions

    DIMENSIONS 27-3/8” (695mm) 24-7/8” (632mm) 6-5/8” (168mm) 24” (610mm) Regency Freestanding Woodstove...
  • Page 6 DIMENSIONS 610mm 125mm 695mm 51mm 578mm 578mm Regency Freestanding Woodstove...

  • Page 7: Installation

    WARNING: DO NOT STORE FUEL another appliance. INSTALLATION WITHIN HEATER INSTALLATION 11) Your Regency Woodstove is not to be connected CLEARANCES. to any air distribution duct. 1) Please read this entire manual before you install and use your new woodstove. Failure...

  • Page 8: Minimum Clearance To Combustibles

    INSTALLATION AUSTRALIA ONLY IMPORTANT The Regency F2402 has been tested with the flue kits listed below. Use only the instructions and clearance dimensions on A default flue kit as listed in AS/NZS 2918:2001 may also be used. this page for heaters to be installed in Australia.

  • Page 9: Combustible Materials

    New Zealand. may also be used. The Regency F2402M has been tested by the AHHA Testing Laboratory These are the only flue kits certified for use with this heater for and conforms to AS/NZS 2918:2001, Report No. ATL19-04.

  • Page 10: Stove Assembly Prior To Installation

    Fasten using a bolt and washer for each corner. Airmate Assembly 3) Push the Regency logo into the two holes in the front bottom left corner of the pedestal cover plate. 1) The airmate sits on top of the stove with the slots in the sides fitting over the curved deflector on the rear stove top.

  • Page 11: Leg And Bottom Shield Assembly

    4) Level the stove by adjusting the levelling bolts in the bottom of each leg. 5) Reinstall cover plate. 6) Install logo plate onto heat shield by placing in 2 holes as shown in diagram. Regency Freestanding Woodstove...

  • Page 12: Flue Baffle & Secondary Air Tube Installation

    If it is not enough space then remove the middle air tube (reverse the procedure in step 1) above), and baffle and then replace everything when cleaning is completed. Front View - Diagram 4 Regency Freestanding Woodstove...

  • Page 13: Brick Installation

    Tighten securely, but do not not become misaligned during shipping. wrench down on the glass as this may cause the glass to break. Regency Freestanding Woodstove...

  • Page 14: Operating Instructions

    Regency Stove causing induction ports at the top of the firebox, just a draft down your chimney. If this occurs, WARNING: Never build a roaring below the flue baffle.

  • Page 15: Ash Disposal

    Failure to do so can result in a serious chimney fire. 7) Your Regency stove can be very hot. You may be seriously burned if you touch the stove while it is operating, keep children, clothing and furniture away.

  • Page 16: Maintenance

    1. Close all draft and damper controls. GLASS MAINTENANCE 2. CALL THE FIRE DEPARTMENT. WOOD STORAGE Your Regency stove is supplied with 5 mm Ways to Prevent and Keep Unit Free Neoceram ceramic glass (Part #846-302) that of Creosote Store wood under cover, such as in a shed, or...

  • Page 17: Parts List

    PARTS LIST STOVE MAIN ASSEMBLY Part # Description Part # Description 850-142 Door Assy-Med Gold 033-953 Air Tube - 3/4" F2402M (Qty: 4) 850-141 Door Assy-Med Black 020-957 Baffle (set) F2402M 850-105 Airmate - Medium 846-302 Glass - Replacement - F2402M 936-243 7/8"...

  • Page 18: Pedestal, Bottom Shield And Legs

    140) 850-126 Legs - Cast Black 850-127 Legs - Cast Gold 850-128 Legs - Cast Brush Nickel 948-216 Logo - Regency PEDESTAL (OPTION) *Not available as a replacement part. BOTTOM SHIELD (OPTION) SEE BELOW FOR CAST LEG CAST LEG FIREBRICK...
  • Page 19 NOTES Regency Freestanding Woodstove...

  • Page 20: Warranty

    FPI Fireplace Products International Ltd. (“the manufacturer”) through its wholly owned subsidiary, Fireplace Products Australia Pty Ltd (for Australia and New Zealand customers) and sold under the Regency® brand of fireplace products (collectively referred to herein as “FPI”), extends this Limited Warranty to the original purchaser of this appliance provided the product remains in the original place of installation.
  • Page 21 Unit must be installed according to all manufacturers’ instructions as per the manual. All Local and National required codes must be met. The installer is responsible to ensure the unit is operating as designed at the time of installation. Revision Date: December 2016 Regency Wood Products Warranty Regency Freestanding Woodstove...
  • Page 22 Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorisation from FPI may void this warranty. INCORRECT INSTALLATION IS NOT COVERED BY WARRANTY. A SERVICE OR CALLOUT FEE WILL BE CHARGED IN THESE CIRCUMSTANCES. Revision Date: November 2016 Regency Wood Products Warranty Regency Freestanding Woodstove...
  • Page 23 (including negligence), statute or otherwise. (b) Loss means any expense, cost or damage of any kind and includes Consequential Loss and a fine or penalty imposed by a statutory or other authority. Revision Date: December 2016 Regency Wood Products Warranty Regency Freestanding Woodstove...
  • Page 24 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com.au/Customer-Care/Warranty-Registration.aspx...
  • Page 25 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 26 Regency Freestanding Woodstove...
  • Page 27 Regency Freestanding Woodstove...
  • Page 28 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ © Copyright 2017, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
