Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS 5263.0, AS/NZS
5263.1.3 and have been certified by the
Australian Gas Association for installa-
tion and operation as described in these
Installation and Operating Instructions.
Your unit should be serviced annually
by an authorised service person.
Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult
an authorised installer, service agency or
the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flam-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
919-864
Models: FG39-NG2
FG39-LPG2
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
June 1, 2018
Advertisement
Table of Contents
Related Manuals for Regency FG39-NG2
Summary of Contents for Regency FG39-NG2
- Page 1 Owners & Installation Freestanding Gas Stove Models: FG39-NG2 FG39-LPG2 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, alteration, What to do if you smell gas: service or maintenance can cause injury or Do not try to light any appli- property damage.
