6" Maxxum Big Flo - Repair Parts Packer Manifold Assembly Parts - Side View; Figure 24. Check Valve And Electrical Bushing Assembly; Table H - Veeder-Root Red Jacket Maxxum Big-Flo Quick-Set Series Installation, Operation & Service Manual

Parts

6" Maxxum Big Flo - Repair Parts Packer Manifold Assembly Parts - Side View

2
rj/051-301-26.eps
Item
1
2
3
4
5
6
6" Maxxum Big Flo - Repair Parts Packer Manifold Assembly Parts - Side View
1

Figure 24. Check Valve And Electrical Bushing Assembly

Table H.

Part No.
144-320-5 Kit - Lock Down Screw
144-317-5 Kit - Check Valve
072-695-1 O-Ring (-366)
072-696-1 O-Ring (-439)
031-334-1 Gasket Flange
144-321-5 Kit - 5 Wire Bushing
Description
37
6
3
4
5
Qty.
1
1
1
1
1
1
