Figure 6. Representative Wiring Diagram, Three-Phase, Two-Wire Control - Veeder-Root Red Jacket Maxxum Big-Flo Quick-Set Series Installation, Operation & Service Manual

Installation
3-PHASE POWER SUPPLY
L1
3
T1
If 115V is not available from power supply,
NOTICE
pilot lights may be operated from any 115V
lighting circuit by controlling with a
4-pole starter. Otherwise, 230V pilot lights
must be used.
L2 L3
Coil
T2 T3
Red
Orange
Black

Figure 6. Representative Wiring Diagram, Three-Phase, Two-Wire Control

Local seals
where required
by code
WARNING
The control box must be grounded for personal
safety. Refer to the National Electrical Codes and
applicable local codes for proper grounding
procedures.
14
Wiring the Conduit Box
rj/051-301-6.eps
(2-Wire shown)
On-Off
switch
Black Blue
Seal
