Table B; Table C - Veeder-Root Red Jacket Maxxum Big-Flo Quick-Set Series Installation, Operation & Service Manual

6” submersible pump
Table of Contents

Advertisement

Installation
Bury
Depth
Riser Length
"A"
"B"
30"
10" (883-442-1)
36"
16" (883-445-1)
42"
21" (883-449-1)
48"
27" (883-449-1)
60"
36" (883-451-1)
72"
51" (883-454-1)
Model Number
Pump Motor
Assembly
HP
UMP200J1-2MB
UMP200J4-2MB
UMP300J4-2HB
UMP300J17-3HB
UMP500J4-2K
UMP500J17-3K
UMP500J6-2K
NOTE: The above readings do not include the added resistance of the power supply wires to the submersible pump. Therefore, for
the readings to fall within the above limits, the resistance should be checked at the submersible pump junction box. If the resis-
tance readings are taken at the control box or magnetic starter, they will be sightly higher.
Disconnect, lock out, and tag power at the panel before servicing the pump and taking
WARNING
these resistance readings.
When servicing equipment, use non-sparking tools and use caution when removing or in-
NOTICE
stalling equipment to avoid generating a spark.
Tank Diameters "C" / Pump Length Requirements "D"
C = 72" / D = 78"
C = 84" / D = 90"
C = 72" / D = 84"
C = 84" / D = 96"
C = 72" / D = 89" C = 84" / D = 101"
C = 72" / D = 95" C = 84" / D = 107"
C = 72" / D = 104" C = 84" / D = 116"
C = 72" / D = 119" C = 84" / D = 131"
Volt
Phase
2
208-230
1
2
208-230
3
3
208-230
3
3
380-415
3
5
208-230
3
5
380-415
3
5
575
3
Starting the System and Completing the Installation

Table B.

C = 96" / D = 102"
C = 96" / D = 108"
C = 96" / D = 113"
C = 96" / D = 119"
C = 96" / D = 128"
C = 96" / D = 143"

Table C.

Winding Resistances (Ohms)
Orange to
Orange to Red
Black
5.4 - 6.6
1.6 - 2.0
2.6 - 3.3
2.6 - 3.3
1.9 - 2.3
1.9 - 2.3
7.6 - 9.3
7.6 - 9.3
1.0 - 1.3
1.0 - 1.3
4.0 - 4.9
4.0 - 4.9
6.3 - 7.6
6.3 - 7.6
17
C = 120" / D = 126" C = 144" / D = 150"
C = 120" / D = 132" C = 144" / D = 156"
C = 120" / D = 137" C = 144" / D = 161"
C = 120" / D = 143" C = 144" / D = 167"
C = 120" / D = 152" C = 144" / D = 176"
C = 120" / D = 167" C = 144" / D = 191"
Red to Black
Blue to Blue
7.0 - 8.6
0.0 - 1.0
2.6 - 3.3
0.0 - 1.0
1.9 - 2.3
0.0 - 1.0
7.6 - 9.3
0.0 - 1.0
1.0 - 1.3
0.0 - 1.0
4.0 - 4.9
0.0 - 1.0
6.3 - 7.6
0.0 - 1.0
