Hydraulic Scheme; Example Of Application - Lovato T-FIRE MODUL Assembling Instructions And Maintenance

PRESSURE LOSS SECONDARY CIRCUIT / PUMP CHARACTERISTICS
P1 P2

HYDRAULIC SCHEME

MI
3
RI
1

ExAMPLE OF APPLICATION

Controller
Boiler-Fireplace stove
7
6
5
4
3
2
1
0
0 200 400
P1 - P2 Heating secondary circuit
1 Heating circulation pump;
4
2 Primary circulation pump (separately supply);
3
Brazed plate iron steel heat exchanger (primary circuit);
4 Degasser / dirty separator system with drain tap and manual air
vent valve;
5 Anticondensation kit (separately supply).
5
2
Accessories
IP UP
T-FIRE MODUL
Assembling instrunctions and maintenance
Wilo YONOS PARA 25/1-6
Wilo RS 15/6-3 KU
600 800 1000 1200 1400
User (secondary circuit)
Boiler
68,6
58,8
49,0
39,2
29,4
19,6
9,8
0
1600 1800 2000 2200
Q (l/h)
25
