Electrical Specifications - Lovato T-FIRE MODUL Assembling Instructions And Maintenance

COMPONENTS:
1 High efficiency pump type Wilo YONOS PARA RS 15/1-6 180 RKA FSM9
(alternative pump type Wilo RS 15/6-3 Ku);
2 Brazed plate iron steel heat exchanger;
3 Degasser / dirty separator system;
4
Primary circuit fitting piece 1" M-110 mm (option high efficiency pump
type Wilo YONOS PARA RS 15/1-6 180 RKA FSM9 or pump type Wilo
RS 15/6-3 Ku);
5 Lamiera di supporto modulo;
6 Manual air vent vale 1/4";
7
Drain tap 1/2";
8 Fitting piece for anticondensation kit;
9 Pipes;
10
Digital controller TC110 24C-65
11 Check valve
PRIMARY CIRCUIT TECHNICAL DATA:
Max working temperature
Max. working pressure
Hydraulic connections
Dimensions wall-hung box
Dimensions built-in box
Circulating pump
Reference temperature flow
Reference temperature return
Max. flow rate
Exchanging surface
SECONDARY CIRCUIT TECHNICAL DATA:
Circulating pump
Flow
Hydraulic connections
Heating head
Reference temperature flow
Reference temperature return
Power exchanged
PRESSURE LOSS PRIMARY CIRCUIT / PUMP CHARACTERISTICS
P1 P1 P2 P2
SECTION 2: T-FIRE MODUL TECHNICAL DATA
90°C
6 bar
F ¾"
480x600x160 mm
500x650x110 mm
RS 15/6-3 Ku
Yonos Para RS
15/1-6 RKA M
80°C
65°C
1,8 m /h
3
0,532 m
2
RS 15/6-3 Ku
Yonos Para RS
15/1-6 RKA M
1,6 m /h
3
F ¾"
3 m.c.a.
65°C
50°C
30 kW (ΔT 15°C)
40 kW (ΔT 20°C)
7
6
5
4
3
2
1
0
0 200
P1 - P2
P1 - P2
Assembling instrunctions and maintenance
2
1
10
11

ELECTRICAL SPECIFICATIONS:

Nominal voltage
Power required Wilo YONOS PARA
Power required Wilo RS Ku
Digital controller power required
Degree of protection
Wilo YONOS PARA 25/1-6
400 600 800 1000 1200
Anticondensatation line
Primary circuit
6
3
7
9
8
4
11
230 V
45 W
93 W
2 W
IP40
Wilo RS 15/7-3 KU
1400 1600 1800 2000 2200
Q (l/h)
5
68,6
58,8
49,0
39,2
29,4
19,6
9,8
0
24
