Current Orbit Marine IC PRO LED Safety Instructions page 8

LOOP IC Controller Programming
®
Programming Daily Weather
To Turn Daily Weather Program On/Off
Press Weather % key
will appear on the LOOP
will be displayed on the bottom of the screen and will display during weather cycle.
Press Weather % key again
turn the weather program off. "W" will disappear from display and your LED light
will run its normal photoperiod with no weather patterns.
To Program Daily Weather
Press Weather % key
Choose any of the four weather patterns - Rolling Clouds
Storm , Full Storm
Press the Hour +
HOUR
+
Press Enter/Resume
RESUME
Daylight lighting period based on your weather forecast. (example: Rolling Clouds @ 20% with a 9 hour
daylight period, cloud cover program will run 6 times throughout the day for 108 total minutes (18 minutes
each time.)
Programming Color Spectrums
The LOOP IC Controller allows you to program & change the color spectrum
®
for DAYLIGHT, SUNRISE/SUNSET, MOONLIGHT and a CUSTOM color. The
color spectrum can be adjusted by changing the intensities of Red, Green, Blue
& White (RGBW) and using the designated color arrow keys on the wireless remote.
The LOOP IC Controller will display R, G, B, W and the level of each color.
®
To Program DAYLIGHT
Press DAYLIGHT key
IC Controller screen. Use the RGBW keys to change the % intensity. Once the
desired color spectrum is achieved, Press and hold the DAYLIGHT key
5 seconds. The LOOP
To Program SUNRISE/SUNSET
Press SUNRISE/SUNSET key
IC Controller screen. Use the RGBW keys to change the % intensity. Once the
desired color spectrum is achieved, Press and hold the SUNRISE/SUNSET key
for 5 seconds. The LOOP
To Program MOONLIGHT
Press MOONLIGHT key
IC Controller screen. Use the RGBW keys to change the % intensity. Once the
desired color spectrum is achieved, Press and hold the MOONLIGHT key
for 5 seconds. The LOOP
***NOTE: YOU MUST press ENTER/RESUME
on wireless remote and hold for 5 seconds. "W"
WEATHER
%
IC Controller screen and the current weather program icon
®
on wireless remote and hold for 5 seconds to
WEATHER
%
, "SET" will display on LOOP
WEATHER
%
and press to designate as a weather pattern.
and Minute - keys to change the daily weather forecast % between 10% and 50%.
-
MINUTE
, the weather program is now programmed and will run automatically throughout the
ENTER
on wireless remote and "L1" will display on the LOOP
IC Controller will display "E1" indicating spectrum is saved.
®
on wireless remote and "L2" will display on the LOOP
IC Controller will display "E2" indicating spectrum is saved.
®
on wireless remote and "L3" will display on the LOOP
IC Controller will display "E3" indicating spectrum is saved.
®
ENTER
RESUME
Orbit Marine IC PRO LED Light
IC Controller screen.
®
, Random Clouds
to put the LOOP IC Controller back into timer mode after programming***
Page 8
TM
Color Adjustment - Press to
adjust Red/Green/Blue/White
color spectrums 0-100%
®
for
®
®
