LOOP IC Controller Programming
®
Program Flow Mode
Press the FLOW mode key
in on the remote. The LOOP
P=Pump
1,2,3=indicates the pump being programmed
P=Wave/Pulse Mode
L=Stream Mode
S=Surge Mode
For example:
P1-S = Pump #1 Surge Mode
P2-L = Pump #2 Stream Mode
Program Water Flow
Press the increase & decrease flow keys
maximum flow rate until the desired flow is reached. Flow rate (between
0-100%) will display on the LOOP
Program Frequency Setting
If programming the eFlux wave pump in either wave or surge mode, adjust
the frequency setting by pressing the increase & decrease frequency keys
until the desired time duration is reached and displayed on the LOOP
The frequency will display on the LOOP
NOTE: Decreasing frequency increases the time duration between min/max flow.
It will appear opposite on the LOOP
decrease wave motion.)
Your setting will be automatically be saved into memory after 10 seconds. No keys need to be selected to
save settings. You can also press Enter/Resume
Designating Primary/Secondary Pump
The LOOP IC Controller can run two pumps in opposite flows to create Gyre flow in an aquarium. Pump #1 is
®
the primary wave pump, Pump #2 can be a primary or secondary pump. When pump #2 is designated a
secondary wave pump, it will run the opposite Wave/Pulse or Surge mode as Pump #1.
To program Pump #2 as a secondary wave pump, press the P/S key and HOLD for 5 seconds. The LOOP
IC controller will display 2-SL when working as a secondary pump. Press P/S key
back to Pump #2 as a primary pump, LOOP

Reset LOOP

IC Controller to Default Settings
®
If you wish to reset your LOOP
settings, press the Main Power key
settings in LOOP IC controller will default back and display will read "-ini".
®
STREAM WAVE you wish to run the pump
SURGE
IC Controller display will show as follows:
®
FLOW
FLOW
IC Controller.
®
IC Controller in seconds.
®
IC Controller (decreasing frequency will increase the time duration and
®
IC controller will display 2-P when running in primary pump mode.
®
IC Controller back to the factory default
®
and hold for 10 seconds. All
to adjust the pumps
IC Controller.
®
at any time to save settings and go to timer program.
ENTER
RESUME
Page 11
Installation Instructions
FREQ
FREQ
for 5 seconds to go
P/S
®
