Orbit Marine IC PRO LED Light Fixture Installation

Fixture Installation

Step 1. Unpack light fixture and components. Remove any plastic film on light fixture (A).
Step 2. Slide the adjustable docking legs (B) on the side of the light fixture (A) to match the length of
your aquarium. (Refer to Orbit Adjustable Tank Mounting Bracket or Orbit Hanging Kit instructions if
using those instead of sliding docking mounts.)
Step 3. Set fixture on aquarium and ensure docking legs fit snug on edges of aquarium.
INSTALLING LOOP IC CONTROLLER AND IC LIGHT & WAVE PUMP MANIFOLD HUB
Step 4. Choose a location underneath your aquarium cabinet free of excessive moisture and/or
saltwater creep. Note: If you want the LOOP
location is 8-12" away from where the IC Light & Wave Pump Manifold HUB (D) will be mounted.
Note: Two (2) additional extension cables (J) are included with each Orbit Marine IC PRO system. These
extension cables can be used for either your Orbit Marine IC Pro LED lights, eFlux Wave or DC pumps.
Step 5. Using included wood mounting screws, mount the IC Light & Wave Pump HUB Manifold
(D) and LOOP IC Contr oller bracket (G) to stand. Slide the LOOP
®
tape is also included as an optional attachment method.
Wood Screws
L2
Step 6. An IR receiving sensor is located on the front of the LOOP
control and on-demand signals from the wireless remote. An additional remote IR sensor (I) is
included in case you choose to mount your LOOP
mount sensor, unwrap cable and attach the IR sensor to your stand using the stick tape. Ensure
cable can reach IC light manifold HUB (D).

CABLE CONNECTIONS

Important:
Before connecting all components
together, please review the following
specifications in regards to the IC
Light & Wave Pump Manifold HUB (D).
Important:
Ensure only 12VDC is used with the
IC Light HUB and only 24VDC is used
with the Wave Pump HUB. If you see
"ERR" on your LOOP controller, it
indicates the wrong power supply
is being used.
Port#3= Communications
IC Controller (F) outside cabinet, ensure the mounting
®
D
L1
Manifold HUB
Pump #3
Pump #2
Pump #1
Communications
IC Controller (F) into bracket. Velcro
®
F
LOOP Controller
IC Controller and is what receives
®
IC controller underneath your aquarium stand. To
®
Power
Power
Power
Pump #2
Pump #1
Pump #3
Wave Pump HUB
Optional
LED Display
Page 3

Installation Instructions

G
Wood Screws
Power
Power
Light #2
Light #1
D
L2 L1
IC LIGHT HUB
Optional
Remote
IR Sensor
®
I
IR Sensor
Light #1
Light #2
LOOP Controller
