- Page 1 BREEZE Manual for use and maintenance + CE Declaration of conformity Breeze Fan Air circulation fan Ag/MIT/UmGB-2488-12/17 Rev 1.1...
- Page 2 This document is destined for the user of the apparatus: it may not be reproduced in whole or in part, committed to computer memory as a file or delivered to third parties without the prior authorisation of the assembler of the system. Munters A/S reserves the right to effect modifications to the apparatus in accordance with technical and legal developments.
-
Page 3: Table Of Contents
4. OPERATING CONDITIONS ........................11 5. INSTALLATION ............................12 5.1 General ..........................12 5.2 Tools required for the installation of the Breeze Fan ............12 5.3 Electrical wirings ........................14 5.4 Spacing of fans ........................15 5.5 Installation of rafter suspension unit ..................16 5.6 Installation of complete motor fixture including motor ............ -
Page 4: Ce Declaration
Apparatus Directive 2006/42/EC with particular reference to the following provisions: UNI EN ISO 12100, UNI EN ISO 13857, CEI EN 60204-1, CEI EN 61000-6-1, CEI EN 61000-6-3 Aars, 11 December 2017 Lasse Kiel Madsen Legal Representative © Munters AB, 2018... -
Page 5: Disclaimer
The information contained herein has been prepared by qualified experts within Munters. While we believe the information is accurate and complete, we make no warranty or representation for any particular purposes. The information is offered in good faith and with the understanding that any use of the units or accessories in breach of the directions and warnings in this document is at the sole discretion and risk of the user. -
Page 6: Safety Aspects
2.2 Installation After transportation, prior to assembly and installation of the Breeze Fan, a verification of the package condition is required: in case of any discrepancy or damage of the fan components, it is necessary to immediately notify the manufacturer or the transporter. -
Page 7: Electrical Connection
Nordac 500E; • automatic Climate Control Munters Temp Man, Automatic Speed Regulator Munters or similar (optional). The characteristics of such devices are shown in the documentation available on http://www.nord.com. The fan is supplied without any wired command and control circuit; in the assembly phase, the installer must predispose a control panel which meets the requirements of the standard CEI EN 60439-3 and proceed to the electrical wiring of the fan in accordance to the indications of the standard CEI EN 60204-1 and IEC 60364. -
Page 8: Residual Risks
(danger resulting from the presence of live parts), the level of voltage present, the prohibition of tampering by unauthorized personnel and the prohibition on the use of liquids on electrical apparatus in the event of fire. © Munters AB, 2018... - Page 9 In areas where the overall sound level reaches excessive values, personal protective equipment must be used. © Munters AB, 2018...
-
Page 10: Before Using
(optional). WARNING • it is mandatory to secure the Breeze Fan with the attachment wires for safety measure so make sure you have the proper mounting structure; • regarding the fan minimum spacing please see Fig.7 on chapter 5.4 •... -
Page 11: Operating Conditions
4. OPERATING CONDITIONS Circulation fans, such as the Breeze Fan, are products to be used to circulate the air inside a structure, thereby creating air movement inside the structure which helps to cool animals down during hot periods. Normal ambient temperature limits are -15°C to +40°C. Maximum altitude is 1000 m above sea level. If a fan is required to operate at a higher altitude, the loss in mass flow (heat removing capacity) due to lower air density should be taken into consideration. -
Page 12: Installation
The verification of the overall stability of the structure is an exclusive responsibility of the customer and/or the end user. Munters will not take any liability for any damage which might rise from the use of a support material not adequately chosen or dimensioned. - Page 13 Please pay attention to use a torque wrench or a calibrated screwdriver to respect the following tightening torque: • M8 Screw: 27 Nm • M10 Screw: 50 Nm unless otherwise indicated • M12 Screw: 90 Nm © Munters AB, 2018...
-
Page 14: Electrical Wirings
5.3 Electrical wirings Electrical installation frequency inverter without reverse for Breeze Fan NORDAC SK 500E Frequency Inverter Munters Nordvestvej 3 9600 Års TLF.98623311 Fig.6 WARNING The power cable must be shielded, suitable for VFD use and the maximum length is 30 m. -
Page 15: Spacing Of Fans
The recommendations should be complied with since they represent the optimum efficiency for the Breeze Fan. A minimum distance of 4m must be left between the lowest part of the Breeze fan and the floor. The installer has also to assess any interference with machinery, balconies, balustrades, or anything else between the floor and the fan, that may interfere with it. -
Page 16: Installation Of Rafter Suspension Unit
When the tilting bracket has been attached to the rafter, it is ready to be fitted with the suspension arm. Fig.10 Fit the suspension arm into the tilting bracket and secure with the accompanying set of bolts. Fig.11 © Munters AB, 2018... -
Page 17: Installation Of Complete Motor Fixture Including Motor
As shown in Fig.13, the gear motor and motor fixture are available as a complete unit. The eye nuts shown are used for 4 x wire attachment. The attachment equipment makes up part of the Breeze Fan’s stabilizing/safety equipment. Fig.13 Suspension arm tightened (must be vertical). -
Page 18: Installation Of Attachment Wires
Tighten the wire with a wire strainer, hard by hand, then turn 3 times (Fig.18). Munters provides an attachment wires kit for the Breeze fan. The attachment wires kit ensure the stability of the Breeze fan and maintain it at its height if, due to external causes, the fan is abnormally stressed or the ceiling mount with the suspension arm only does not guarantee a sufficient solidity over time. -
Page 19: Installation Of Hub
WARNING Munters does not accept any responsibility for not using the attachment wires kit for installation. WARNING It is important that when the fall protection is fitted, the suspension arm does not deviate from the vertical position. 5.8 Installation of hub Important! Fig.19... -
Page 20: Wind Sensor (Optional)
Only if the wind is not too strong, the Breeze Fan starts to work. If the wind speed is not so strong, the Breeze Fan starts the rotation of the blades (after the Starting Time more or less 1 minute). - Page 21 Inverter stand alone Fig.24 Stand-alone Breezefan: left side => with anemometer (the Inverter have to be the SK520E); right side: without anemometer (the inverter is the SK500E). © Munters AB, 2018...
- Page 22 If there are more than one Breeze Fan connected into a Master/Slave daisy chain, the behaviour of the Master Breeze Fan manages also all the others connected inverters (Slaves Breeze Fan). The connection between all the inverters has made with only two wires (signal and ground). See the following connection scheme.
-
Page 23: Commissioning
Wait until the electrical power has been switched off and the fan has come to a complete stand still. Lock the electrical switch in the off position with a pad lock while working on the fan. © Munters AB, 2018... -
Page 24: Technical Data
20.62 SK90T1/4 TF SK572.1 24.58 WARNING NordGear motor is designed to work only in conjunction with its NordGear inverter. Any other configuration is not authorized. 7.4 Inverter specifications Breeze Fan without anemometer Current Current Code Power Voltage Frequency (Single phase) - Page 25 50 - 60 WARNING The inverter equipping Breeze fan can be connected either to single phase line (@ 230 V) or to three-phase line (@ 230 V only). Applied frequency can be 50 Hz or 60 Hz. © Munters AB, 2018...
-
Page 26: Maintenance
3m ,4m and 5m) of the propeller hub screw (Fig.26) Check the blade, hub and spider for signs of damage or cracks and replace if necessary Check that all the structural screws of the fan and its support are correctly tightened © Munters AB, 2018... -
Page 27: Munters Ab
Check the safety cable Check the attachment wires for fraying or damage and replace if necessary Check motor status and remove dust deposit from it Check structural integrity of the fan Check the gear reducer for oil leakage © Munters AB, 2018... - Page 28 Nordvestvej, 3 9600 Aars, Denmark Tel: +45 986 233 11 Fax: +45 986 213 54 aghort@munters.dk Breeze fan is developed and produced by Munters A/S, Denmark www.munters.com Australia Phone 61 2 8843 1594, agh.info@munters.com.au, Brazil Phone +55 41 3317 5050, contato@munters.com,...
