P O S MInI II
Touch screen pos. 1
Via the touch screen you enter data to Mini II using a touch
pen or your fingers.
Compartment for Vectron dealer information pos. 2
Your Vectron dealer should have inserted a card with con-
tact information to this compartment.
Brightness sensor pos. 3
The brightness sensor meters the illuminance and controls
the display brightness.
Keyboard film pos. 4
Via the flat keyboard you enter data to the Mini II by
pressing the keys. Underneath the keyboard film a sheet is
inserted, which illustrates the functions.
Keys pos. 5
The 108 keys are allocated to the functions that you can
carry out by pressing them.
Keyboard bar pos. 6
The keyboard bar serves for lifting the keyboard film.
Operator lock pos. 7
By means of an operator key you log in to Mini II via the
operator lock.
