- Page 1 WC flush plate forPrevista Visign for Style 20 Instructions for Use for concealed cisterns 3H, concealed cisterns 3L, concealed cis‐ terns 3F, concealed cisterns 3S Model Year built: Modell: 8610.1 from 09/2018 en_INT...
- Page 2 WC flush plate forPrevista Visign for Style 20 2 from 17...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Standards and regulations Intended use 2.2.1 Areas of use Product description 2.3.1 Overview 2.3.2 Technical data Handling Assembly information 3.1.1 Required material and tools Assembly... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e. -
Page 6: Product Information
DIN 4109 Intended use 2.2.1 Areas of use Suitable cisterns The flush plate is intended for the actuation of flushes on Viega con‐ cealed cisterns. Installation is only possible in the following Viega concealed cisterns: Concealed cistern 3H 3L concealed cistern... -
Page 7: Product Description
Product information Product description 2.3.1 Overview Fig. 1: Scope of delivery Installation frame flush plate actuating rods retaining bolt 2.3.2 Technical data Flush volume The flush volumes for the flush actuation are: Small flush volume: approx. 2–4 litres Large flush volume: approx. 3.5–7.5 litres For the setting of the flush see Ä... -
Page 8: Handling
Handling 3 Handling Assembly information 3.1.1 Required material and tools Tool The following tools are required for mounting: cutting knife Assembly 3.2.1 Prepare cistern Requirements: The cistern is fitted into the pre-wall. The pre-wall is tiled. Cut into the sticky tape of the shaft cover. Remove the shaft cover. -
Page 9: Mounting The Flush Plate
Handling Cut into the corners of the revision shaft. Fold the sides of the revision shaft outwards up to the tile level and snap them off. 3.2.2 Mounting the flush plate Turn the cover plate lock 90° in counter-clockwise direction. Remove the cover plate. - Page 10 Handling Close the corner valve. Loosen the flexible hose at the filling valve. INFO! For setting the flush volume, see Ä Chapter 3.3.1 „Setting the flush volume“ on page 15. Open the corner valve for a few seconds to flush the pipe. Close the corner valve.
- Page 11 Handling Connect the flexible hose to the filling valve. Re-open the corner valve. INFO! Check the filling valve for leak tightness. Insert the cover plate into the cistern. Turn the cover plate lock by 90° in a clockwise direction. WC flush plate forPrevista Visign for Style 20 11 from 17...
- Page 12 Handling Put on the installation frame. Insert the retaining bolts. Turn the retaining bolts by 90° in a clockwise direction. Align the installation frame. To fix the retaining bolts, turn safety rings in a clockwise direction. WC flush plate forPrevista Visign for Style 20 12 from 17...
- Page 13 Handling INFO! For installation from the front into the concealed cisterns 3H, 3L, 3S. Determine the distance for the actuating rods. A: 30–50 mm B: 10–30 mm C: 10 mm If necessary, cut the actuating rods to length. INFO! For installation into concealed cistern 3F. Determine the distance for the actuating rods.
- Page 14 Handling INFO! For installation from above into the concealed cisterns 3L, Determine the distance for the actuating rods. A: 20–40 mm B: 10–20 mm If necessary, cut the actuating rods to length. Insert the actuating rods as far as they will go. Align the actuating rods.
-
Page 15: Commissioning
Handling Mount the flush plate. ð The flush plate is mounted. Commissioning 3.3.1 Setting the flush volume Fold the tabs forward. Lift the drain valve. WC flush plate forPrevista Visign for Style 20 15 from 17... -
Page 16: Errors, Faults And Remedy
Handling Remove the drain valve through the revision opening. Set the large flush volume at the drain valve. Set the small flush volume at the drain valve. Errors, faults and remedy Error Cause Remedy The WC does not flush. The cistern is not yet completely Wait until the cistern is sufficiently full. -
Page 17: Care And Maintenance
Handling Care and maintenance 3.5.1 Care tips Use normal soap or a mild cleaning agent for regular care and preven‐ tion of lime scale on the flush plate. Under no circumstances should scouring agent or scratching objects be used. Strong stains can be removed using typical household cleaner. Rinse the detergent thoroughly with clear water after the prescribed exposure time.
