- Page 1 ALFA F ALFA FV INSTALLATION OPERATING AND SERVICING INSTRUCTIONS NOTICE D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN INSTALLATIE-, GEBRUIK- EN ONDERHOUD INSTRUCTIES NOTICIAS DE INSTALACIÓN, UTILIZACIÓN Y MANTENIMIENTO ISTRUZIONI D’INSTALLAZIONE, USO E MANUTENZIONE ANLEITUNG ZU INSTALLATION, GEBRAUCH UND WARTUNG exellence in hot water...
- Page 2 NOTICIAS DE INSTALACIÓN, UTILIZACIÓN Y MANTENIMIENTO alfa : Con quemador de gasoil ACV BM R 31 alfa : Con quemador de gasoil ACV BM 1 LN 1 INSTRUZIONI DELL’ INSTALLAZIONE, DELL’ USO E DI MANUTENZIONE alfa : Con bruciatore a gasolio ACV BM R 31...
- Page 3 °C 1 2 3 4 5 6 7 8 9 10 11 12 S3 B4 N T1 T2 S3 B4 SQK 349 QAAD50 (QAAD70) QAC32 QAD22 bl bk br 19 18 17 16 15 14 13 12 11 10 19 18 17 16 15 14 13 12 11 10 N T1 T2 N T1 T2 230V-50 Hz...
- Page 5 B 23 C 13 / C 33 Alfa - F Alfa - FV...
- Page 6 BM R 31 BM 1 LN 1...
- Page 7 Oil supply Essential to ensure that the system works properly. STARTING UP Filling the tank and domestic hot water circuits Comissioning of the ACV BM 1 LN 1 - burner Essential for personal safety and Troubleshooting the burner environmental protection. SERVICING Danger of electrocution.
-
Page 8: Installation
• Safety unit The tank safety unit must be ACV approved and calibrated to 7 bar. It must be easily removable in order to give access to the flue pipes The valve discharge must be connected to the waste water disposal when servicing the boiler. -
Page 9: Oil Supply
Shut-off valve It is important to switch the boiler off before carrying out any work. CONTROLLER KITS KIT 1: ACV 13.00 / Basic (see illustration D) OIL SUPPLY Basic kit for regulating initial flow temperature according to weather conditions. It comprises: a temperature regulator with analogue clock, wall-mounted water temperature sensor (-30/130 °C), external... - Page 10 7. Set the Summer/Winter selector switch (3) to the desired position. RECOMMENDATION 8. Switch the on/off switch (2) to the ON position. ACV recommend that boilers should be serviced at least once a year. The burner must be serviced and tested by a competent engineer. COMISSIONING OF THE ACV...
-
Page 11: Build Features
• The ALFA F model with output power adjustable between 19.4 • The ALFA F boiler is fitted with the ACV BM R 31 oil burner. and 34.2 kW is fitted with the ACV BM R 31 oil burner. •... -
Page 12: Technical Specifications
LEGEND OF BOILER (see illustration K) TECHNICAL SPECIFICATIONS Top cover Domestic hot water outlet Jacket Central heating return GENERAL POINTS Central heating flow pipe Chimney flue reducer Units are shipped fully assembled, tested and packed on a timber Inner ring-shaped tank containing the domestic hot water base with shockproof edges and protected by a heat-shrunk plastic Insulation film. -
Page 13: Effective Dimensions
EFFECTIVE DIMENSIONS 1404 1404 80 / 125 Weight when empty Effective dimensions of Alfa F Effective dimensions of Alfa FV DOMESTIC HOT WATER PERFORMANCES Operating at 80 °C Peak flow 40 °C (∆T = 30 °C) L/10’ Peak flow 40 °C (∆T = 30 °C) -
Page 14: Using The Boiler
Pump USER GUIDE Motor High voltage transformer ACV BM 1 LN 1 OIL BURNER USING THE BOILER DESCRIPTION To fit out our ALFA Fuel boiler with air valve, we needed a really high LEARNING YOUR WAY AROUND THE CONTROL PANEL performance burner to give perfect combustion. - Page 15 • Thermostat adjustable between 60 and 90 °C (item marked 1, SAFETY UNIT (domestic hot water) (item marked 1, illustration H) Central heating systems are generally designed to illustration B). A monthly inspection is recommended: operate at a maximum of 80° C. When used at lower temperatures, Lift the lever on the emptying device for a few seconds to ensure that a 3-way mixer valve installed on the heating flow pipe (see illustration G)
- Page 16 NOTES...
