alfa alfa Sprint SV/MV Installation, Operating and Servicing Instructions EN • 1 664Y0200.C...
Page 2
INDEX WarningS Who should read these instructions Symbols Recommendations Applicable standards Warnings DESCriPTiOn General description Operating principle Design characteristics Boiler description USEr gUiDE Use of the boiler Setting the burner to safety mode TEChniCal CharaCTEriSTiCS General Operating condition limits Dimensions Domestic hot water performances General characteristics inSTallaTiOn...
Who should read these instructions • The parts may only be replaced by genuine factory parts. You will find a list of the spare parts and their ACV reference These instructions should be read by: number at the end of this document.
64 mm. Each flue way has baffles made of special • Alfa Sprint models S/SV have a fixed output of 31.95 kW steel designed to improve the heat exchange and reduce the respectively and are fitted with the ACV BG 2000-S or SV gas flue gas outlet temperature. burner.
DESCRIpTIoN boiler description 1. Control panel 2. Detachable casing cover (access to turbulators) 3. Measuring unit with condensate trap (optional) 4. Chimney reducing pipe 5. Polyurethane foam insulation 6. Outer body containing the primary water 7. Side casing 8. Base 9.
uSER GuIDE use of the boiler Gauge pressure in the heating system Your system must be equipped with a heating safety valve calibrated to 3 bar and fitted with a pressure gauge. Your system should be serviced at least once a year by a qualified engineer.
TECHNICAL CHARACTERISTICS dimensions general The appliances are supplied fully assembled, tested and packed standing on a timber base with impact protection strips and wrapped in heat-shrunk plastic film.When the appliance arrives, remove the packaging and check that no parts have been damaged in transit.
INSTALLATIoN boiler room Chimney connector Alfa S/SV/M/MV : Type B23 (fig.6) Important The chimney must be connected to the boiler by means of a metal pipe rising at an angle from the boiler to the chimney. • Never obstruct the ventilation. A chimney connection is required.
Vertical terminal Horizontal terminal Condensate trap 2.06 This table is based on material provided by ACV and cannot be generalised. fig. 7 : Chimney connectors type C xx Example of calculation : The following diagram consists of the following components (Ø 80 mm) : •...
• A pump; Safety group • A 3-way manual valve. This valve The safety group of the water tank must be approved by ACV can be motorised if required; and calibrated to 7 bar; the group's valve discharge must be •...
INSTALLATIoN electrical connections Alfa Sprint S/SV (fig. 13 Principle of supply 1 2 3 4 5 6 7 8 9 10 11 12 L1 N The boiler operates on a single-phase supply of 230 V/50 Hz. You should install a control box with main switch and 6 A fuses externally to the boiler to allow the boiler to be isolated from the supply for servicing and repairs.
Page 13
INSTALLATIoN Alfa Sprint M/MV (fig. 14 9 10 11 12 start Max. min. Pri 230V - 50/60 Hz SEC 18V - 2,0 VA Typ EI 30/15,5 BV 030-7308.OS 1 2 3 4 bg 2000-m/mV alfa sprint m/mV 1 2 3 4 5 230 V-50Hz 230V-50Hz EN •...
Gas burner ACV BG 2000-M/MV The ACV BG 2000-M/MV burner is based on the technology of the ACV BG 2000-S/SV burner but offers the benefits of a modulating burner. The burner's output is constantly adjusted to suit the fluctuating demand for heat, thus optimising operating efficiency.
Page 15
BuRNER CHARACTERISTICS BURNER Bg 2000-S/SV Burner chamber plate Flame inspection window Only SV models Ignition cable Ionisation cable Control / monitoring relay BURNER Bg 2000-M/MV Burner chamber plate Flame inspection window Only MV models Box containing the p.c.b. Ignition cable Control / monitoring relay Ionisation cable PWM connector...
Page 16
BuRNER CHARACTERISTICS operating principle of the burner 1. Air 2. Gas AIR/GAS mixture control (fig. 12) 3. Venturi The fan draws air in across the venturi. This creates a vacuum 4. Fan P1 at the venturi neck. The gas valve regulator now reacts to 5.
Page 18
4. Take off the burner chamber plate by undoing the two The offset (4) is set at the factory and requires no retaining nuts. adjustment. Nevertheless ACV recommends that you check this setting. (Refer to the table of setting parameters).
Page 19
BuRNER CHARACTERISTICS fig. 17 fig. 21 burner maintenance [fig. 22] 1. After dismantling the burner, check the condition of the ignition electrode (1) and ionisation electrode (2), the insulation (3) and the burner chamber plate seal (4). Replace these items if necessary. 2.
BuRNER CHARACTERISTICS fault table Corrective measures Problems Condensation in the chimney: Smell of flue gas: Insufficient heating: The burner switches to safety mode after lighting: Noisy pump: Not enough hot water: Pump not running: Burner fails to light: The manual reset high limit thermostat is tripped: Reasons Chimney is cold and/or not lined Boiler T°...
Replace the p.c.b. Replace the boiler thermostat / potentiometer Fill and vent the system and the boiler Insert the NTC sensor in the pocket correctly ACV provides details of training courses on the maintenance of BG 2000 burners EN • 21 664Y0200.C...
CoMMISSIoNING AND MAINTENANCE filling the hot Water and heating circuits recommendation ACV recommends that you have the boiler serviced at least once a year. Boiler servicing and checking must be carried out by a qualified engineer. imPOrTanT It is essential that the water tank is under pressure before the heating circuit is filled.
Page 26
alfa s / sV alfa m / mV en : Complete control panel en : Complete control panel 24614063 24614065 fr : Tableau de commande complet fr : Tableau de commande complet nl : Volledig bedieningspaneel nl : Volledig bedieningspaneel es : Panel de mandos completo es : Panel de mandos completo it :...
Page 27
alfa sV / mV 51305000 en : Flue connection concentric Ø 80/125 mm en : ‘Cerablanket’ insulation Ø 430 / 23 mm 507F3034 fr : Raccordement cheminée concentrique Ø 80/ 125 mm fr : Isolation cérablanket Ø 430 / 23 mm nl : Schoorsteenaansluiting concentrisch Ø...
