- Page 1 ECO - HL - HLE Installation, Operating and Servicing Instructions 100 / 130 / 160 100 / 130 / 160 / 210 / 240 100 / 130 / 160 / 210 / 240 EN • 1 661Y0400.F...
-
Page 2: Table Of Contents
INDEX WARNING Who should read these instructions Symbols Recommendations Applicable standards Warnings Packing INTRODUCTION Description of the specifications Description of operation TECHNICAL CHARACTERISTICS Operating condition Wiring diagram INSTALLATION INSTRUCTIONS Installation INSTALLATION Dimensions Central heating connections Domestic hot water connection COMMISSIONING Filling the tank Check to be carried out before start-up Setting the thermostat... -
Page 3: Warning
An approved installer must carry out the assembly, commissioning, maintenance and repair of the system, in accordance with current standards in force. ACV shall not accept any responsibility for damage caused by non- Danger of burns compliant location of the system or by use of the parts or connections not approved by ACV for this application. -
Page 4: Introduction
Models Losses in °c/h Exterior of casing vinyl coated and polypropylene cap. ΔT = 40°C ECO 100 / HL 100 / HLE 100 0,28 Electric heating element in HLE ΔT = 40°C ECO 130 / HL 130 / HLE 130... -
Page 5: Technical Characteristics
TECHNICAL CHARACTERISTICS OPERATING CONDITION Operating temperature Maximum service pressure [tank filled with water] - Heating circuit: 3 bar - Maximum temperature: 90°C - DHW circuit: 10 bar Water quality Test pressure [tank filled with water] • Chlorides: < 150 mg/L [304 Stainless steel] - Heating circuit: 4,5 bar <... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALLATION The HLE models must be assembled with the heating This hot water tank should not be installed where it will be element to the bottom (DHW pipes to the bottom). exposed to outside weather conditions. Choose the most appropriate location according to the position of the boiler and the proximity of the domestic hot water distri- In horizontal configuration, the peak output and the bution system, in order to reduce heat losses and minimise the... -
Page 7: Installation
2. Safety valve calibrated to 3 bar PIPE DIMENSIONS 3. Expansion vessel Models Central heating 4. Drain cock 5. Isolation valve, heating system ECO / HL / HLE 100 L 1”1/4 6. Room thermostat ECO / HL / HLE 130 L 1”1/4 7. -
Page 8: Domestic Hot Water Connection
Wall Cold / hot water Models Auxiliary connexion mounting connections ECO / HL / HLE 100 L Ø 3/4” [M] Ø 3/4” [F] ECO / HL / HLE 130 L Ø 3/4” [M] Ø 3/4” [F] ECO / HL / HLE 160 L Ø... -
Page 9: Commissioning
There is a risk of scalding from hot water! ACV recommends the use of a thermostatic mixing valve set to provide water at 60 °C or less. • The water heated to wash clothes, dishes and for other purposes can burn and cause serious injury. -
Page 10: Maintenance
