4. Operation
– Push head stop upwards according to
the height of the person to be meas-
ured.
– The person to be measured stands with
his or her back to the measuring rod.
The back and head must be straight.
– Slide the head stop along the measur-
ing rod until it touches the head.
– Read off body height at the read-off
mark.
If the above-mentioned instructions are
followed, accuracy greater than ± 2 mm
can be achieved.
5. Cleaning
Clean the measuring rod and the outside of the display housing as required using a do-
mestic cleaning agent or commercially-available disinfectant. Follow the manufacturer's
instructions.
Under no circumstances use abrasive or acid cleaners, white spirit, benzene or the like for
cleaning. Such substances can damage the high-quality surfaces and the printing.
6. What do I do if...
... the slide unit slips down?
– Tighten up the screw on the slide unit
using a small screwdriver.
Model 240
GB
11
