Baxtran STI User Manual page 30

Error Message Description
1 Pan
2 Top cover
3 "+"screw
4 Battery cover
5 Level bubble 14.7
6 Acrylic board
7 Overlay
8 Front display board
9 Printer fixed bracket
10 Printer paper cutter
11 TP230 printer module
12 Printer cover
13 Printer cover
14 TP230 printer axis
15 "+" round self thread screw
16 Printer button
17 Spring
18 Paper baffel
19 TP230 printer control board
20 Paper axis
21 Roll paper
22 Load cell bracket rubber
23 Internal hexagon screw
24 Spring washer
25 Washer
26
Load cell bracket
27
Load cell
28
Hexagon screw
29
Hexagon nut
30 "+" round self thread screw
31 Load cell bracket
32 6V10Ah lead acid battery
33 "+" round self thread screw
34
Cable gland
35
Calibration switch board
36
Interface board
37
"+" round self thread screw
38 Round adaptor jack
39 Bottom cover
40 Fixed foot
41 Foot
42 Seal plastic
43
Fragile paper
30
USER MANUAL STI
QTY Spec
1
1
5 M4x8
1
1
1
1
1
1
1
1
1
1
1
9 ST4x12
1
2
1
1
1
1
4
4 M6x20
4 M6
4 M6
1
1
4 M4x16
4 M4
4 ST4x20
1
1
4 ST4x8
4
1
1
9 ST3x8
1
1
4
4
2
2
EN
