Key Board & Display - Baxtran STI User Manual

• Adaptor connects into your AC power socket.
Pluggable equipment must be installed near an easily accessible socket outlet with a protective ground/ earth contact.
• Turn on the power switch. If you want to turn off, press again the switch backward.
• Display will be show the scale capacity and will be starting self checking.
• After self checking, display will be come to normal weighing mode.
• Then you can start your operation.
Note: Initial Start Up.
Warm-up time of 15 minutes stabilizes the measured values after switching on.
STI
5. KEYBOARD DISPLAY
