Summary of Contents for Viega 6163.2
- Page 1 Multiplex drain/overflow functional unit Instructions for Use Model Year built: 6163.2 from 06/2015 en_INT...
- Page 2 Multiplex drain/overflow functional unit 2 from 17...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview 2.2.2 Technical data Accessories Handling Assembly information 3.1.1 Mounting conditions 3.1.2 Installation dimensions... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e. -
Page 6: Product Information
The drain / overflow is suitable for extra long bathtubs. Detailed information regarding all bathtub models and the corre- sponding Viega drains / overflows can be found in the catalogue or on the Internet. An equipment set with rotatable rosette and valve cone must be pur- chased separately. -
Page 7: Technical Data
Product information 13 14 15 16 Fig. 1: Component overview fixing screw valve top double seal drain elbow union nut sliding ring seal odour trap pipe extension 10 - overflow pipe 11 - Bowden cable 12 - sleeve 13 - overflow unit 14 - profile seal 15 - O-ring 16 - fixing flange... -
Page 8: Accessories
Product information DN (nominal diameter) drain sup- 40 / 50 mm port Length of Bowden cable 1070 mm Length 100–680 mm Height 180–480 mm Dimensions and installation depth Ä Chapter 3.1.2 „Installation dimensions“ on page 10 Water head seal 50 mm Accessories The accessories shown here are not included in the scope of delivery. - Page 9 Product information Equipment set Multiplex Visign M5: Model 6162.01 Optional accessories Equipment set with water level increase The water level of the overflow can be increased by 5 cm with the equipment set. The equipment set contains a rotatable rosette, a fixing flange, a valve cone, a fixing screw, a flange cover and a mounting aid for the drain of the functional unit.
-
Page 10: Handling
Handling 3 Handling Assembly information 3.1.1 Mounting conditions The following requirements exist for the mounting of the drain / over- flow: The bathtub is installed. The drainage line is installed all the way to the bathtub. The underside of the bathtub is accessible. 3.1.2 Installation dimensions Fig. -
Page 11: Assembly
Handling Assembly 3.2.1 Mounting overflow Proceed as follows to the mounting of the overflow: Fit profile seal in the overflow unit. Push the rubber sleeve onto the overflow unit pipe until the lower edge is flush with the edge of the overflow pipe. Place the O-ring in the annular gap of the fixing flange. -
Page 12: Connecting Overflow And Drain
Handling Place the double seal onto the drain unit in such a way that the recess is positioned over the connecting pipe. Pull the edge of the double seal over the edge of the drain. Hold the drain with double seal onto the drain opening from below. Pull the upper part of the double seal through the drain hole. -
Page 13: Connecting The Wastewater System
Handling Requirements: The overflow is mounted in the overflow opening. The drain is securely mounted on the base of the bathtub. NOTICE! Connections where the pipes are not inserted far enough into each other become leaky. For this reason, maintain a minimum insertion depth of 15 mm for every connection. -
Page 14: Mounting Equipment Set
Handling Requirements: The overflow and drain units are installed on the bathtub. The connection between overflow and drain has been made. If the wastewater pipe only has a diameter of 40 mm, cut off drain elbow. Push union nut, sliding ring and seal onto the drain elbow. Screw the union nut on the drain unit. -
Page 15: Leakage Test
Handling To avoid damage to the rosette and valve cone, only mount the equip- ment set after finishing all other work on the building site. Proceed as follows: Align and fit rotatable rosette. Fit valve cone. Turn rotatable rosette to check function and alignment. The opening of the valve cone should be 2–3 cm wide when opened. -
Page 16: Control
Handling Control The drain / overflow are controlled via rotatable rosette on the overflow. Proceed as follows to open or close the drain: Turn rotatable rosette to the left. ð The drain closes itself. Turn rotatable rosette to the right. ð... -
Page 17: Disposal
Handling Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Multiplex drain/overflow functional unit 17 from 17...
