- Page 1 Instructions for Use Simplex drain/overflow, flat version for standard bathtubs and for bathtubs with drain hole Ø52 Model Year built (from) 6168.2 09/2019...
-
Page 2: Table Of Contents
Table of contents Table of contents About these instructions for use 1.1 Target groups 1.2 Labelling of notes 1.3 About this translated version Product information 2.1 Intended use 2.1.1 Areas of use 2.2 Product description 2.2.1 Overview 2.2.2 Technical data Handling 3.1 Assembly information 3.1.1... -
Page 3: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 4: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 5: Product Information
Product information Product information Intended use 2.1.1 Areas of use NOTICE! Risk of damage due to unsuitable liquids To avoid damaging the drain, only introduce the following liquids: Typical household wastewater with temperatures up to 95 °C The pH value must be higher than 4 but lower than 10. The Simplex drain/overflow is a combined drain and overflow for bath‐... -
Page 6: Product Description
Product information Product description 2.2.1 Overview Fig. 1: Component overview valve cone fixing screw valve top Sealing Sealing drain unit with odour trap Bowden cable Flexible overflow pipe overflow unit 10 profile seal 11 fixing flange 12 rotatable rosette Simplex drain/overflow, flat version... -
Page 7: Technical Data
2.2.2 Technical data Drainage capacity (at an accumu‐ 0.92 l/s lation height of 300 mm) with Viega odour trap Overflow capacity (at an accumu‐ 0.63 l/s lation height of 60 mm) with Viega odour trap Diameter of bathtub drain hole... -
Page 8: Handling
Handling Handling Assembly information 3.1.1 Mounting conditions The following requirements exist for the mounting of the drain / over‐ flow: The bathtub is installed. The drainage line is installed all the way to the bathtub. The underside of the bathtub is accessible. 3.1.2 Installation dimensions Fig. -
Page 9: Required Tools And Materials
Handling 3.1.3 Required tools and materials Tool The following tools are required for mounting: socket spanner (size 14) fine-toothed saw flat-blade screwdriver Material The following material must be purchased separately and must be avail‐ able during mounting: Odour trap Assembly 3.2.1 Mounting overflow Proceed as follows to the mounting of the overflow:... -
Page 10: Connecting The Wastewater System
