3 - XY Transport Module Replacement Procedure
b) Enter password
c) Enter password
d) Scroll down in the list of settings until you find the ExitHandoffAdjustmentX setting.
e) If the XY Transport bumped into the Exit Transport, decrease the ExitHandoffAdjustmentX
setting by selecting the number in the list, pressing the
on the on-screen keypad and pressing the
f) If the card did not push far enough into the exit ramp, increase the ExitHandoffAdjustmentX
setting by selecting the number in the list, pressing the
on the on-screen keypad and pressing the
g) If the card is off-center from the green roller and is too close to the front of the EC2000, increase
the ExitHandoffAdjustmentY setting by clicking the number in the list, pressing the
then entering the new number on the on-screen keypad and pressing the
10 steps at a time.
h) If the card is off-center from the green roller and is too close to the back of the EC2000, decrease
the ExitHandoffAdjustmentY setting by clicking the number in the list, pressing the
then entering the new number on the on-screen keypad and pressing the
10 steps at a time.
i) Press the
Save
j) Repeat these steps from step 1 until the card clamps correctly when it exits the printer.
9) Navigate to Menu >
page.
10) Press the
Unclamp Card
11) Press the
Exit Eject
12) Press the button to return to the Status page.
Status
