Magtek ExpressCard 2000 Manual page 13

3 - XY Transport Module Replacement Procedure
17) If the card doesn't fit all these conditions, adjust the handoff location by following these steps:
a) Navigate to
Menu
password page.
b) Enter password
c) Enter password
d) Scroll down in the list of settings until you find the PrinterHandoffAdjustmentX setting.
e) If the card did not push far enough toward the second clamp, decrease the
PrinterHandoffAdjustmentX setting by selecting the number in the list, pressing the
then entering the new number on the on-screen keypad and pressing the
f) If the card did not make contact with the plastic portion of the clamp or did not press on the
justifier and raise it a little bit, decrease the PrinterHandoffAdjustmentY setting by clicking the
number in the list, pressing the
and pressing the
g) Press the
Save
h) Repeat the steps in this section until the card clamps correctly when it exits the printer. Keep the
card in the XY Transport for the next section.
3.3.3 How to Calibrate XY Transport to Exit Transport Handoff
To calibrate where the XY Transport goes to push a card into the exit rollers, follow these steps:
1) Make sure you have moved a card to the XY Transport as described in the previous section.
2) Navigate to >
Menu
page.
3) Press the XY To Embosser
4) Press the
XY To Exit
5) Make sure the XY Transport does not bump against the Exit Transport.
6) Make sure the first green roller on the exit ramp is centered on the card.
7) Make sure the card is pushed into the exit ramp past the point where the first green roller touches it.
8) If the card doesn't fit all three of these conditions, adjust the handoff location by following these
steps:
a) Navigate to
Menu
password page.
ExpressCard 2000| Instant Issuance Card Personalization System | XY Transport Module Replacement Procedure
Page 13
Figure 3-6 - Card Clamps On Card (FRONT VIEW)
> >
Settings Edit Config
1234567 and press the
to open the
7654321 Configuration Editing
C button, then entering the new number on the on-screen keypad
button.
E
button to save your changes.
> >
Settings Service
button.
button.
> >
Settings Edit Config
to open the first
E button to open the second password page.
page.
to open the
MCP Commands
to open the first
Configuration Editing
C
E button.
Controller Commands
Configuration Editing
button,
