Installation instructions
Range hood DFPQ5/DFPQ6/DFPQ9/DFPQ12
Built-in hood
Operating modes: extracted air/recirculation air
The appliance should be installed by qualified personnel only.
Each step must be carried out and checked in full in the order specified.

Validity

These installation instructions apply to:
61001 (DFPQ12, construction width 120 cm)
61002 (DFPQ9, construction width 90 cm)
61003 (DFPQ6, construction width 60 cm)
61004 (DFPQ5, construction width 55 cm)
H4.2608 (motor housing, extraction, standard)
H4.2609 (motor housing, extraction, short)
H4.2606 (motor housing, recirculation, standard, built-in hood)
H4.2607 (motor housing, recirculation, short, built-in hood)

General notes

If other firing systems are being used at the same time (e.g. wood, gas, oil or coal-fired heating appliances), safe operation is
only possible providing a room negative pressure of 4 Pa (0.04 mbar) is not exceeded at the location of the appliance. Risk
of toxic fumes! An adequate flow of fresh air must be guaranteed e.g. via non-closable openings in doors or windows and in
combination with an air-intake/exhaust-air wall box or by other technical means.
If the appliance is installed over hobs, each cooking zone must be fitted with an ignition fuse and the minimum distances
(see 'Dimensions') must be adhered to.
Efficient repairs can only be guaranteed if it is possible to uninstall the complete appliance at any time without causing any
damage.

Identification plate

Remove the grease filters. The identification plate is located on the inside of the appliance.

Supplied installation accessories

All fixing elements are contained in the scope of delivery.

Extraction mode

The extracted air must not be fed into a chimney which is used for exhausting fumes from appliances burning gas or other
fuels.
Observe the local fire regulations.
