  • Page 1 Operating instructions DFPQS Range hood...
  • Page 2 The product family (model number) corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Type Product family Size system DFPQS9 61010 DFPQS6 61011 DFPQS5 61012 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2016...
  • Page 3: Table Of Contents

    Contents 1 Safety precautions  4 Symbols used ...................... 4 General safety precautions .................  5 Before using for the first time ................ 5 Correct use...................... 6 Children in the home....................  6 Note on use ...................... 7 2 Disposal  9 3 Your appliance  10 Appliance description .................. 10 Extraction model .................... 10...
  • Page 4: Safety Precautions

    Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in damage to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ▸...
  • Page 5: General Safety Precautions

    1 Safety precautions General safety precautions ▪ Read the operating instructions before using the appliance for the first time! ▪ This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved.
  • Page 6: Correct Use

    1 Safety precautions Correct use ▪ The appliance is designed for use in the home for extracting cooking odours from above a cooking area. ▪ Any repairs, modifications or manipulations to the appliance, especially any electrically live parts, may only be carried out by the manufacturer, its Cus- tomer Services or a similarly qualified person.
  • Page 7: Note On Use

    1 Safety precautions Note on use ▪ If the appliance is visibly damaged, do not use it. Contact our Customer Services. ▪ If the appliance is not functioning properly, disconnect it from the power supply immediately. ▪ If the mains cable of the appliance is damaged, it must be replaced by Cus- tomer Services in order to avoid hazard.
  • Page 8 1 Safety precautions ▪ When carrying out maintenance work on the appliance, including replacing the light bulb, cut off the electricity supply to the appliance: remove the screw fuse from the holder or switch the circuit breaker off, or disconnect from the mains supply.
  • Page 9: Disposal

    Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪...
  • Page 10: Your Appliance

    Your appliance Appliance description The appliance is designed for use in the home for extracting cooking odours from above a cooking area. This particular model can be used to air extract or recirculate air. Extraction model The integrated fan extracts cooking fumes and smells from above the cooking surface.
  • Page 11: Construction

    3 Your appliance Construction 1 Operating elements 2 Combi filter 3 Grease filter 4 Illumination Operating and display elements Buttons Illumination ON/OFF OFF button Power level 1 selection button Power level 2 selection button Power level 3 and intensive level selection button Timer...
  • Page 12: Operating The Appliance

    Operating the appliance Using for the first time Configuring the appliance The appliance can be used in the extraction or recirculation mode. The appli- ance is set up as a recirculation hood with 1.5 kg of activated charcoal ex-fact- ory. With this setting, the service life of the activated charcoal filter is 450 op- erating hours.
  • Page 13: Operation

    4 Operating the appliance Operation Switching the appliance on ▸ Pull out the flat deflector plate. The appliance is most effective when the flat deflector plate is fully pulled out. ▸ Press the , button. – The appliance switches on at the corresponding power level. –...
  • Page 14: Intensive Level

    4 Operating the appliance Intensive level The intensive level can be selected when the appliance is switched on. ▸ Depress the button for 2 seconds. – The button flashes. After 5 minutes, the appliance switches back to the previously selected power level.
  • Page 15: Care And Maintenance

    Care and maintenance Cleaning the housing Take care that no water gets into the housing of the appliance! If wa- ter gets into the housing, it can cause damage. Do not use abrasive cleaners, scouring pads, steel wool, etc. for cleaning, as they can damage the surface.
  • Page 16 5 Care and maintenance Do not damage the grease filter. Cleaning ▸ Clean the grease filters and combi filters on their own in an upright position in a dishwasher. ▸ Set the dishwasher to an «intensive» – or «heavy» soiling – wash pro- gramme.
  • Page 17: Replacing The Activated Charcoal Filters

    2 years or whenever the button flashes. Spent activated charcoal filters can be disposed of in the household waste. The activated charcoal filters have been developed especially for this appli- ance and can only be ordered from V-ZUG Ltd's Customer Services.
  • Page 18 5 Care and maintenance Removing the activated charcoal filter ▸ Disconnect the appliance from the mains power supply. ▸ Cover over the hob to protect it from getting damaged. ▸ Remove and clean the combi filters and grease filters. ▸ Carefully take the metal cover A down and out.
  • Page 19: Changing The Light Bulb

    5 Care and maintenance Inserting the activated charcoal filter ▸ Fix the metal cover B to the activated charcoal filter with the 4 side clips. ▸ Insert activated charcoal filter 1 with metal cover at an angle, lay flat and then pull straight down to rest on holder.
  • Page 20: Trouble-Shooting

    Trouble-shooting What to do if ... … the illumination is not working Possible cause Solution ▪ Fuse or automatic circuit ▸ Replace the fuse. breaker for electrical in- ▸ Reset the automatic circuit breaker. stallations in the home is defective. ▪...
  • Page 21: Accessories And Spare Parts

    Accessories and spare parts Please give product family of the appliance and exact description of the ac- cessory or spare part when ordering parts. Grease filter Grease filter holder for 90 cm hood width Combi filter Activated charcoal filter...
  • Page 22: Technical Data

    Technical data Electrical connection ▸ See identification plate. ▸ Remove the metal grease filters. – The identification plate is located on the inside of the appliance.
  • Page 23: Index

    Index Accessories ........... 21 Operating elements ........11 Activated charcoal filter ....... 10 Operating the appliance ......12 Replacing.......... 18 After-running time.......... 14 Appliance description ........10 Packaging ............9 Product family..........2 Care..............15 Children in the home........6 Queries ............
  • Page 24: Notes

    Notes...
  • Page 27: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an onsite visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our progress- ive service agreements.
  • Page 28 Clean grease filters Saturation indicator for activated charcoal filters ▪ Flashing: Replace activated charcoal filters J61010013-R02 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
