  • Page 1 Operating instructions DFN5 / DFN6 Range hood...
  • Page 2 The product family (model number) corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Type Product family Size system DFN5 DFN6 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2016...

  • Page 3: Table Of Contents

    Contents  2 1 Safety precautions  5 Symbols used ..................... 5 General safety precautions .............. 6 Before using for the first time .............. 7 Correct use.................... 7 Children in the home ................. 7 Note on use.................... 8 2 Disposal  10 3 Appliance description  11 Appliance description................ 11 Extraction model..................
  • Page 4 10 Service & Support  27...

  • Page 5: Safety Precautions

    Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in dam- age to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ▸...

  • Page 6: General Safety Precautions

    1 Safety precautions General safety precautions ▪ Read the operating instructions before using the appliance for the first time! ▪ This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved.

  • Page 7: Before Using For The First Time

    1 Safety precautions Before using for the first time ▪ The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/ electrician carry out the necessary work. ▪ Dispose of the packaging material in accordance with local regulations. Correct use ▪...

  • Page 8: Note On Use

    1 Safety precautions Note on use ▪ If the appliance is visibly damaged, do not use it. Contact our Customer Services. ▪ If the appliance is not functioning properly, disconnect it from the power supply immediately. ▪ If the mains cable of the appliance is damaged, it must be replaced by Cus- tomer Services in order to avoid hazard.
  • Page 9 1 Safety precautions ▪ When carrying out maintenance work on the appliance, including replacing the light bulb, cut off the electricity supply to the appliance: remove the screw fuse from the holder or switch the circuit breaker off, or disconnect from the mains supply.

  • Page 10: Disposal

    Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪...

  • Page 11: Appliance Description

    Appliance description Appliance description The appliance is designed for use in the home for extracting cooking fumes and smells from above the cooking surface. The model can be used to extract or recirculate air. Extraction model A fan draws cooking fumes and smells from above the cooking area. The metal grease filters clean the extracted air, which is passed through a connect- ing pipe fitted with an integrated non-return valve and through the air duct to the outside.

  • Page 12: Features

    3 Appliance description Features ▪ Flat pull-out deflector plate ▪ 2 metal grease filters ▪ Illumination ▪ 1 activated charcoal filter (not included in scope of delivery) ▪ 1 extractor fan with 4 power levels – 1 = low, 2 = medium, 3 = high, 4 = intensive extraction rates. –...

  • Page 13: Operating Elements

    3 Appliance description Operating elements Slide switch Switch extractor fan on/off (4 power levels) Switch illumination on/off Depending on the model and features, the specification of your appliance may differ in individual details from the standard specification described.

  • Page 14: Operating The Appliance

    Operating the appliance Switching the appliance on To switch the illumination and ex- tractor fan on, the deflector plate must be pulled out. ▸ Pull the deflector plate out. The appliance is most effective when the deflector plate is fully pulled out.

  • Page 15: Switching The Appliance Off

    4 Operating the appliance Switching the appliance off ▸ Push the deflector plate completely – This switches off the extractor fan and the illumination even if the switch is not set to If the deflector plate is pulled slightly out again, the extractor fan switches on at the level set and the illumination comes on.

  • Page 16: Care And Maintenance

    Care and maintenance Cleaning the housing Take care that no water gets into the housing of the appliance! If water gets into the housing, it can cause damage. Do not use abrasive cleaners, scouring pads, steel wool, etc. for cleaning, as they can damage the surface. Remove the screw fuse or switch off the circuit breaker.

  • Page 17: Cleaning The Metal Grease Filters

    5 Care and maintenance Cleaning the metal grease filters The metal grease filters must be cleaned at least once a month with normal use. If properly cared for, the metal grease filters should provide unlimited years of service. Removing the metal grease filters Do not damage the metal grease filters.
  • Page 18 5 Care and maintenance Cleaning ▸ Clean the metal grease filters in the dishwasher. ▸ Select an «intensive» or «heavy» wash programme with a warm prewash. Cleaning may cause the metal grease filters to become discoloured. However, this will not affect the functioning of the filters in any way. If no dishwasher is available: ▸...

  • Page 19: Replacing The Standard Activated Charcoal Filter

    5 Care and maintenance Replacing the standard activated charcoal filter Remove the screw fuse for the appliance or switch off the circuit breaker. Standard activated charcoal filters are only used in the recirculation model. The standard activated charcoal filter is to be replaced after an operating time of three to six months.

  • Page 20: Cleaning And Replacing The Long-Life Activated Charcoal Filter

    5 Care and maintenance Cleaning and replacing the long-life activated charcoal filter Remove the screw fuse for the appliance or switch off the circuit breaker. ▸ Clean the long-life activated charcoal filter in the dishwasher. ▸ Select an «intensive» or «heavy» wash programme with a warm prewash. Wash separately so that no food debris can become stuck to the filter.

  • Page 21: Replacing The Halogen Light Bulb

    5 Care and maintenance Replacing the halogen light bulb Remove the screw fuse for the appliance or switch off the circuit breaker. Halogen light bulbs get hot during operation! Allow them to cool down first. ▸ Remove the metal grease filters. –...

  • Page 22: Trouble-Shooting

    Trouble-shooting What to do if … … the illumination is not working Possible cause Solution ▪ Fuse or automatic circuit ▸ Replace the fuse. breaker for electrical in- ▸ Reset the automatic circuit breaker. stallations in the home is defective. ▪...

  • Page 23: Accessories And Spare Parts

    Accessories and spare parts Please give model number of the appliance and exact designation of the ac- cessory or spare part when ordering parts. Halogen light bulb 230 V / 28 W Metal grease filter Standard activated charcoal filter Long-life activated charcoal filter The halogen light bulb is also available from specialist retailers.

  • Page 24: Technical Data

    Technical data Electrical connection ▸ See identification plate. ▸ Remove the metal grease filters. – The identification plate is located on the inside of the appliance.

  • Page 25: Index

    Index Removing.......... 17 Model number ..........2 Accessories ..........23 Appliance Switching off........ 15 Switching on........ 14 Operating element ........13 Appliance description ......11 Operating the appliance ......14 Care............16 Packaging ..........10 Children in the home........7 Product family..........
  • Page 26 Validity............2 What to do if The appliance is not extracting enough air ........ 22 The illumination is not working .. 22...
  • Page 27 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an onsite visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our progress- ive service agreements.
  • Page 28 To switch off ▸ Slide the switches to position or push in the deflector. J808013-R04 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
