5.2 Technical data
Double pump interface (DP)
Interface
Voltage
Frequency
Cable length

5.3 Scope of delivery

• IF-Module
• Metal EMC cable gland Pg 9 (Pg 9 and Pg 7 in case of DP model)
• Installation and operating instructions
• Connecting cable for double pump interface
• 2x2x0.22 mm² twisted and shielded pair (DP model)
• 2x0.5 mm² light plastic-sheathed cable, 670 mm long (other models)

6 Description and function

6.1 Description of the IF-Modules
The Stratos IF-Modules expand the pump to include additional inputs and out-
puts and provide the connections for the double pump interface. The DP model
plays a special role: it is used for through-connection of a BUS line for commu-
nication and provides the connections for the double pump interface.
28
Wilo-specific, sustained short circuit protection,
cannot be twisted out of place
Max. 10 Vss
Approx. 150 kHz
Max. 3 m
