MTSMC-LSP3-U Power Draw

Radio Protocol
3.3 Volts
LTE
5 Volts
LTE

Mounting Hardware

The board has three mounting holes at corners. Use #4 or M3 hardware for mounting the SocketModem to the
board. Refer to the Mechanical Drawings for more information.

Recommended Parts

Manufacturer
PEM (Penn Engineering &
Manufacturing)
RAF Electronic Hardware
RAF Electronic Hardware
®
SocketModem Cell MTSMC-LSP3 Device Guide
Live Cellular
Connection Connection
with SIM Idle, No Data
Installed,
No Data
44 mA 102 mA
25 mA 69 mA
Part
Surface Mount Standoff
3/16" Hex Female Standoff
4.5mm Hex Female Standoff
Average Measured TX Pulse (Avg)
Current at Amplitude Current for
Maximum Power GSM850 or Peak
Current for HSDPA/LTE
985 mA 1.11A
603 mA 676 mA
SPECIFICATIONS
Total Inrush Charge
Measured in
Millicoulombs
0.457 mC
0.520 mC
Part Number
SMTSO-M3-4ET
2051T-440-S-12-Zinc
1251-3005-S-12-Zinc
