Insignia NS-RTM10BK0 User Manual page 13

14 Install the center hinge to the left side with the two screws you removed previously.
15 Remove the screw that secures the door stops from the bottom of the freezer door, then remove the door stops and
install them on the bottom left side.
Door stops
16 Install the freezer compartment door.
17 Remove the door bushing hole cover on the top left side of the freezer compartment door, then move the door
bushing from the top right of the door to the top left of the door. Install the hole cover in the bushing hole on the top
right of the door.
Door bushing
Center hinge spacer
Center hinge
Door bushing
Screws
Freezer door
www.insigniaproducts.com
NS-RTM10BK0/NS-RTM10WH0/NS-RTM10SS0
Bushing hole cover
Refrigerator door
