Summary of Contents for Taski swingo XP-R
- Page 1 XP-R / XP-M *12091-14* V001 / 12091-14 1423...
- Page 2 Declaración de Conformidad UE EU-conformiteitsverklaring Product: Scrubber drier for commercial use Model: swingo XP-R/XP-M Type: COXPR.1 | COXPR.2 | COXPR.1X | COXPR.2X Serial Number: Refer to the rating label on the machine Trademark: ...
- Page 3 Applicable EU Directives: Directive 2006/42/EC | Directive 2004/108/EC Harmonised standards applied: EN 60335-1 / EN 60335-2-72 / EN 62233 / EN 55014-1 / EN 55014-2 / EN 61000-3-2 / EN 61000-3-3 / Предприети са вътрешни мерки, за да се Des mesures internes ont été...
-
Page 4: Table Of Contents
Safety instructions Failure to follow these instructions may re- Due to their design and construction, TASKI machines comply sult in faults! with the relevant essential health and safety requirements of the EC directives; they therefore carry the CE sign. - Page 5 Do not transport other persons and objects these instructions for use in the Accesso- with this machine. ries chapter or which have been recom- mended by a TASKI consultant. Any other brushes might impair the safety and func- Caution: tions of the machine.
- Page 6 Cleaning products Notice: TASKI machines are designed in such a way that optimal cleaning results can be achieved if TASKI cleaning products are used. Other cleaning products may cause mal- functions and damage to the machine or the environment. Therefore, we recommend the exclusive use of TASKI cleaning products.
-
Page 7: Structural Layout
Structural layout 37 38 XP-R XP-M 20 21 in the control panel 26 Drain hose Driving handles 27 Fresh water tank (Flextank) Emergency stop 28 Recovery tank Horn 29 Pump and intake filter Driving switch 30 Dirt sieve Suction hose 31 Tank lid Main cord for internal battery charger 32 Suction filter... -
Page 8: Batteries
Optionally available on-board chargers are adapted to the bat- tery size and contain several charging characteristics which are adjusted ex works or by a TASKI service technician for recommended batteries. • Attention! The battery poles are always en- This regulation also applies to the use of stationary (external) ergized. -
Page 9: Prior To Commissioning
Open battery compartment for maintenance Attention: • The machine must be switched off. Before decommissioning the machine for a longer period, the batteries must under- Caution: go a complete charging cycle. After com- Before opening the battery compartment pletion, the charger is disconnected from make sure that both tank areas are empty. - Page 10 Max. permissible water temperature Do not use pads which are worn out or 60 °C/140 °F. dirty. Use original TASKI brushes only. Diversey recommends using cold water Failure to observe these instructions may since hot water will adjust to the floor...
-
Page 11: Beginning Work With The Machine
• The dosing cup remains in the Flextank after dosage. the brushes rotate. Notice: • Select the desired dosage by pressing the +/ TASKI offers an automatic dosage feature - buttons from level as an option; It is possible to mount it addi- 1-6. - Page 12 ECO mode Cleaning start • The ECO mode is activated by pressing the • If the machine is switched on and the ECO mode ON/OFF button. operator is standing on the running board, the machine starts moving as This reduces the speed of the suction motor. Set the dosage of the cleaning solution to soon as the driving switches are op- level 2 and the brush pressure to level 1.
-
Page 13: End Of Operation
• Drive on for some meters so that the brushes keep on Notice: rotating for a short time to avoid dripping. The machine guiding might be impaired in Very important for TASKI contact pads! case of special combinations of flooring/ • Press the Brush drive ON/OFF button. contamination and cleaning product. - Page 14 XP-R Draining and cleaning the recovery and fresh water tank (Flextank) • Press the brush release with your foot. Notice: Drain water or cleaning solution must be disposed of in compliance with the national regulations. XP-M Notice: • Pull the locking lever. When draining the recovery tank, the reg- ulations of the detergent supplier regard- ing personal protective equipment must be...
-
Page 15: Service, Maintenance And Care
Diversey service ● technicians Service intervals TASKI machines are high-quality machines which have been checked for safety in the factory and by authorized inspectors. • Carefully tilt the tank backwards until Electrical and mechanical parts are subject to wear and aging it is lying on the floor. -
Page 16: Malfunctions
Malfunctions Malfunction Possible causes Troubleshooting Page • Turn the key Machine is switched off • Connect the battery switch with the Emergency switch is pressed machine • Check/replace fuse Main fuse is defective • Contact your service partner Machine without function cannot be switched on. -
Page 17: Error Codes
Technical information Machine XP-R XP-M Working width Squeegee width Dimensions (LxWxH) 131 x 95 x 130 131 x 95 x 130 Maximum weight of operational machine Rated voltage Rated power, nominal 1150 1100 Fresh water tank, nominal Weighted sound pressure level L according to ISO 11201 dB(A) Weighted effective acceleration value according to ISO 5349-1... -
Page 18: Transport
Transport Disposal Notice: Attention: After withdrawal from service, the machine This machine may only be lifted using and accessory parts must be adequately lifting gear (e.g. hoist, loading ramp, etc.). disposed of in compliance with the nation- al regulations. Please contact your Diversey service partner for help.
