Supported Gestures - Cypress CY8CKIT-044 Quick Start Manual

• Connect the board to your computer using the
provided USB cable
Note: This demo does not require driver installation,
although this may continue in the background

Supported gestures

RGB color change
CY8CKIT-044 QUICK START GUIDE
1
• Bring your nger closer to the CapSense
• Control the RGB LED's color and brightness using
the Gesture Pad
Note: Once your nger is removed from the Gesture
Pad, the PSoC 4200M device will switch to low-power
mode. On wakeup using proximity sensing, the RGB
LED will turn on with the last selected color
3
VIBGYOR color change
Pad to wakeup the system using proximity sensing.
The on-board RGB LED will turn on with white color
The RGB LED will turn off after 3 seconds if your
nger is taken away from the Gesture Pad
Brightness control
2
Gesture
®
