Installation and
Care Instructions
1" Horizontal
Aluminum Blinds
Reveal
with
™
MagnaView
™
THANK YOU for purchasing a Hunter Douglas product. Your
new blind has been custom built for you from the highest quality
materials. Once in your window, it will provide you with a lifetime
of beauty and trouble-free use.
Getting Started
• Remove the blind from the package. Keep the packaging until the
blind operates to your satisfaction.
• Check the diagram to make sure you have the necessary parts.
• Contents of your hardware package may vary depending upon
mounting options chosen.
7/8" Bracket
Spacer
1/2" Bracket
Spacer
End Mount
Bracket
Hold-Down
Bracket
and Screw
Tools needed for installing your shade.
• Measuring Tape
• Pencil
• Power Drill,
1
/
" Hex
4
Driver and Drill Bits
In addition, you may need fasteners designed to work with your
specific mounting surfaces:
Mounting Surface
Drywall, Plaster
Wall Anchors, Expansion Bolts
(Not Provided)
Metal
Sheet Metal Screws
(Not Provided)
Wood
No. 6 Hex Head Screws
(Provided)
Extension
Brackets
Installation
Brackets
• Carpenter's Level
• Flat Blade Screwdriver
• Phillips Screwdriver
Fastener
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HunterDouglas Reveal with MagnaView
Summary of Contents for HunterDouglas Reveal with MagnaView
- Page 1 THANK YOU for purchasing a Hunter Douglas product. Your new blind has been custom built for you from the highest quality materials. Once in your window, it will provide you with a lifetime Installation and of beauty and trouble-free use. Getting Started Care Instructions •...
- Page 2 • Attach the installation brackets with two screws through the two holes in the rear of the brackets. Visit our Web site at hunterdouglas.com • Use a carpenter’s level to check that the tops of the brackets are aligned at the same height before tightening the screws.
- Page 3 End Mount Bracket Attachment with the bottom of the slot aligned with the center of the “D” in the HunterDouglas logo on the bottom rail end caps. • Attach the short side of the end mount brackets to the mounting •...
- Page 4 Troubleshooting Pull Cord to the Outside Pull Cord Down and to Lock Blind PROBLEM SOLUTION Toward the Center to in Position Raise and Lower The blind does not raise Check inside the headrail. and lower evenly. Make sure no obstructions keep the mechanism from turning.
