IMPORTANT!
Read this entire installation manual
Installation
to ensure proper installation, then
file this manual with the owner or
maintenance department.
Compliance and conformity to local
codes and ordinances is the
responsibility of the installer.
Pressurized plumbing fixtures must
be installed in accordance with
manufacturer's recommendations.
The supply piping to these devices
must be securely anchored to the
building structure to prevent
unnecessary movement of the
installed device when operated by
the user. Use extreme caution when
installing the device to prevent
damage to the exposed significant
surface.
Separate parts from packaging and
Packing List
make sure all parts are accounted
for before discarding any packaging
T H
IS
E
S ID
U P
material. If any parts are missing,
do not begin installation until you
obtain the missing parts.
Flush water supply lines before
making connections. DO NOT use
pipe dope on any faucet or supply
connections. Possible solenoid
contamination could occur which
will void any warranty. Teflon tape is
the recommended sealant.
Product warranties may be found
under "Product Information" on our
web site at www.bradleycorp.com.
800 Series SensorScan™ Parts List
1
6
3
3
4
8
2
7
5
Figure 1
ITEM
QTY.
PART NO.
DESCRIPTION
800 SERIES SENSORSCAN™
BATTERY IR FAUCET w/USER
1
1
S53-269
ADJUSTABLE TEMPERATURE
CONTROL (COMPLETE UNIT)
2
1
S65-141
FILTER
3
1
S65-156
MOUNTING PREPACK
4
1
S65-157
FLEX HOSE/CHECK STRAINER
S45-1805
TRIM PLATE 4" CTRSET (OPT)
5
1
S45-1313
TRIM PLATE 8" CTRSET (OPT)
6
1
S05-142
AERATOR
7
1
269-1542
WRENCH (to mount faucet)
8
1
269-1540
OPERATION BOX
Aerada
SensorScan
Remove
protective
3
film from
bottom of
3
faucet and
clean the
surface.
S53-269 800 Series SensorScan™ Battery IR
S53-293 800 Series SensorScan™ Battery IR
S53-294 800 Series SensorScan™ Battery IR
Installation
P.O. Box 309, Menomonee Falls, Wi 53052-0309
TEL. 262-251-6000
http://www.bradleycorp.com
215-1200 Rev. F; EN 08-205 (page 1 of 2)
800 Series
™
Faucet
™
with User Adjustable Temperature
Control
with User Adjustable Temperature
Control and 4" Trim Plate
with User Adjustable Temperature
Control and 8" Trim Plate
OBSOLETE
FAX 262-251-5817
4/30/08
