Multiplex Trio E-WLAN module
Instructions for Use
for the operation of Multiplex Trio E by mobile end devices (APP)
Model
6146.224
en_INT
Year built:
from 06/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multiplex Trio E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viega Multiplex Trio E

Summary of Contents for Viega Multiplex Trio E

  • Page 1 Multiplex Trio E-WLAN module Instructions for Use for the operation of Multiplex Trio E by mobile end devices (APP) Model Year built: 6146.224 from 06/2016 en_INT...
  • Page 2 Multiplex Trio E-WLAN module 2 from 15...

  • Page 3: Table Of Contents

    Product description 2.3.1 Overview 2.3.2 Technical data Handling Mounting instructions Assembly 3.2.1 Installation situation Trio E or E2 3.2.2 Installation situation Trio E3 Commissioning 3.3.1 Establishing a connection with mobile end devices Disposal Multiplex Trio E-WLAN module 3 from 15...

  • Page 4: About These Instructions For Use

    This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use.

  • Page 5: About This Translated Version

    German/European guidelines in this manual: The information is not binding for other countries and territories and should, as mentioned, be considered as support. Multiplex Trio E-WLAN module 5 from 15...

  • Page 6: Product Information

    Intended use The WLAN module controls the Multiplex Trio E fittings by means of a mobile end device (such as smartphone or tablet). The WLAN module is easy to refit for already installed Multiplex Trio E fittings (art. no. 662295, 682972, 684655).

  • Page 7: Product Description

    Protection class Power supply 6–15 V Transmission frequency 2.4 Ghz Material (casing) NOTICE! Regularly update your browser and operating system. Should you have any questions on compatibility, please contact the Viega Service Center. Multiplex Trio E-WLAN module 7 from 15...

  • Page 8: Handling

    9 ) Mounting the Multiplex Trio E fitting together with the WLAN module If the WLAN module is mounted together with the Multiplex Trio E fit- ting, the assembly steps for the Multiplex Trio E fitting must be observed as well.

  • Page 9: Installation Situation Trio E3

    Plug the connection cable of the WLAN module into the slot with the „Display“ . designation Replace the casing cover and use the Phillips-tip screwdriver to tighten the two screws. 3.2.2 Installation situation Trio E3 Multiplex Trio E-WLAN module 9 from 15...
  • Page 10 Remove the plug at the „Display“ slot. Plug the removed display cable into the WLAN module. Insert the WLAN module (cable outlet left-hand side) at an angle into the gap between battery and power pack. Multiplex Trio E-WLAN module 10 from 15...

  • Page 11: Commissioning

    Commissioning 3.3.1 Establishing a connection with mobile end devices There are two ways to connect the Multiplex Trio E fitting with its mobile end devices. Peer-to-peer connection via the router in the home network (Internet connection required) We recommend to use a direct connection only during the initial installa- tion.
  • Page 12 1.1.1.1 in Step 4: Open the Internet browser at the end device. Type the address line and press Enter to confirm. ð The user interface of the Multiplex Trio E is indicated. Connecting the WLAN module with the home network Requirements: A direct connection has been established between an end device and the WLAN module.
  • Page 13 Step 1: Open the Internet browser in the end device. Type 192.168.1.1 in the address line and press Enter to confirm. ð The user interface of the Multiplex Trio E is indicated. „Network“ . Step 2: In the menu, open the item Step 3: Select the personal home network from the list of available networks.
  • Page 14 Step 1: Open the Internet browser in the end device. Type trio-e.viega.de in the address line and press Enter to confirm. ð The registration screen of the Multiplex Trio E is indicated. Step 2: Enter your email and password and click „Login“...

  • Page 15: Disposal

    „Start“ button to call up the user interface of the Step 4: Press the Multiplex Trio E. Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Multiplex Trio E-WLAN module 15 from 15...
