Compact Ejector SCPMc
Short Instruction Manual
Note: These brief operating instructions were originally written in German and have been translated into Eng-
lish. The operating instructions describe the basic functions of the device. They are intended to provide a quick
start for experienced users. The complete description of the device can be found in the detailed operating in-
structions at www.schmalz.com or is available on request. These brief operating instructions make no claim to
being exhaustive. Store in a safe place for future reference. Subject to technical changes without notice. No re-
sponsibility is taken for printing or other types of errors.
Published by
© J. Schmalz GmbH, 06/19
This document is protected by copyright. J. Schmalz GmbH retains the rights established thereby. Reproduction of
the contents, in full or in part, is only permitted within the limits of the legal provisions of copyright law. Any mod-
ifications to or abridgments of the document are prohibited without explicit written agreement from
J. Schmalz GmbH.
J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0
schmalz@schmalz.de
EN-US · 30.30.01.02085 · 00 · 06/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schmalz SCPMc Series
Summary of Contents for Schmalz SCPMc Series
- Page 1 The complete description of the device can be found in the detailed operating in- structions at www.schmalz.com or is available on request. These brief operating instructions make no claim to being exhaustive. Store in a safe place for future reference. Subject to technical changes without notice. No re- sponsibility is taken for printing or other types of errors.
-
Page 2: Ejector Structure
1 Ejector Structure Compressed air connector (marking 1) Vacuum connector (marking 2) Operating and display elements 4.1 M8 electrical connector, 6-pole 4.2 JST electrical connector, 5-pole Optional: Compressed air connector for exter- Silencer (marking 3) nal blow off EB (marking 1A) Valve screw for blow off volume flow 2x mounting hole 2 ... -
Page 3: Displaying The Basic Settings (Slide Show)
Navigation is divided into three menus: • The main menu: for standard applications • The Extended Functions (EF) menu: for applications with special requirements • The Info menu (INF): for reading out system data such as counters, the software version, etc. The following information can be shown on the display: •... -
Page 4: Checking The Delivery
1. Compare the entire delivery with the supplied delivery notes to make sure nothing is missing. 2. Damage caused by defective packaging or occurring in transit must be reported immediately to the carrier and J. Schmalz GmbH. 6 Installation Instructions CAUTION... -
Page 5: Electrical Connection
CAUTION Noise pollution due to incorrect installation of the pressure and vacuum connections Hearing damage 4 Correct installation. 4 Wear ear protectors. 7.1 Connecting the Compressed Air and Vacuum 4 Connect the compressed air hose to the connection (1). Connect the vacuum hose to the connection (2). For threaded connectors, the maximum tightening torque is 1 Nm. -
Page 6: Pin Assignments
Black “Parts control” output (SP2) Gray “Blow off” signal input — Pink Not used When using a Schmalz connection cable, part no. 21.04.05.00488 (see accessories) JST socket Symbol Function 24 V power supply “Suction” signal input Ground “Parts control” output (SP2) “Blow off”...
