Tripp Lite NSS-G16D2 Owner's Manual

16 10/100/1000Mbps Port Gigabit L2 Web-Smart
Managed Switch, 2 SFP Slots, 36 Gbps, Web, 8-
Outlet 120V PDU/Surge Protect
MODEL NUMBER: NSS-G16D2
Combines a Web-Smart 16-port Gigabit network switch with a basic PDU/surge protector in one 1U rack-
mount unit. Ideal for monitoring and controlling an LAN and powering equipment in a small-to-medium
distributed network.
Description
The energy-efficient NSS-G16D2 16-Port Gigabit L2 Web-Smart Managed Switch does more than
complete your home or office LAN. It also features a basic 120V 15A PDU to distribute reliable AC power
to critical IT equipment in your wiring closet, server room or equipment rack. Two dedicated mini-GBIC
SFP ports are also included for uplinking data to other switches via optical fiber or copper.
This switch features 16 twisted-pair RJ45 Gigabit Ethernet ports that support auto-negotiable 10/100/1000
Mbps and auto MDI/MDIX cross-over detection functions for convenient plug-and-play capability. Easy-to-
read LEDs indicate connection and activity status for each port. Built-in management software lets you
monitor and control each connected device via secure web-based interface. Each port supports up to 2
Gbps with full duplex.
The rear panel contains eight NEMA 5-15R outlets that supply continuous power to connected devices.
Your equipment is protected by 3860 joules of surge suppression, as well as front-panel LEDs that let you
monitor line status at a glance. A 12A circuit breaker trips if the current drawn by connected equipment
exceeds the PDU's maximum load rating.
The NSS-G16D2 supports IEEE802.3az Energy Efficient Ethernet standards. The heavy-duty metal
housing mounts into 1U of an EIA-standard 19-inch rack using the included hardware. The six-foot input
cord with NEMA 5-15P plug connects to a protected UPS, generator or mains input AC source.
Features
1 / 4
Highlights
IP-MAC-Port-Binding, ACL,
Storm Control
Port Security, DHCP Snooping,
802.1x, L2
WEB management, SNMP,
RMON features
16 ports and 2 dedicated Mini-
GBIC SFP slots
Enterprise-level, security and
layer 2 management
3860-joule surge protection
rating
Built-in 8-outlet PDU with
diagnostic LEDs
Package Includes
NSS-G16D2 16-Port Gigabit L2
Managed Network Switch
Rack-mounting hardware
Owner's manual
