• Make sure network cables are properly seated. A clicking sound will be made when a cable is installed correctly. • If the power cord is damaged, do not attempt to connect the switch. Contact a Tripp Lite Service Representative for assistance.
Accessing the Management Configuration Interface After powering the switch for the first time, the Network Smart Switch can be configured using a Web browser. To access the switch, the management computer and the switch must be set to the same subnet. The IP address of the management computer must be configured manually. The switch’s default IP address is 192.168.1.200 and the default subnet mask is 255.255.255.0.
Page 4
If the Line Fault indicator illuminates and power is not present at the outlets, the PDU’s surge-suppression components have been compromised as a result of surge damage. For service, contact Tripp Lite Customer Support at www.tripplite.com/support to remedy the problem or receive instructions about return, repair or exchange.
Page 5
Product Features NSS-G24D2 Front Panel: Rear Panel: Gigabit Ethernet Ports: These 24 twisted-pair RJ45 ports support auto-negotiable 10/100/1000 Mbps and auto MDI/MDIX cross-over detection functions for true “plug and play” capability. Note: Not compatible with PoE (Power over Ethernet) applications. Power ON/OFF LED: An LED illuminates to indicate the switch is receiving power.
Page 6
If the Line Fault indicator illuminates and power is not present at the outlets, the PDU’s surge-suppression components have been compromised as a result of surge damage. For service, contact Tripp Lite Customer Support at www.tripplite.com/support to remedy the problem or receive instructions about return, repair or exchange.
Installation 1U Rackmount Installation Mount the switch using four user-supplied rackmount screws . The user must determine the fitness of the rackmount screws to hold the unit in the rack before installation. Connect the switch to a properly grounded outlet. The POWER LED will illuminate when the switch turns on.
5-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of five (5) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
• No intente conectar el switch si está dañado el cable de alimentación. Para asistencia, póngase en contacto con un Representante de Servicio de Tripp Lite. • Nunca intente instalar o usar el switch durante una tormenta eléctrica.
Acceso a la Interfaz de Configuración de Administración Después de encender el switch por primera vez, el Switch Inteligente de Red puede configurarse usando un navegador de Web. Para acceder al switch, la computadora de administración y el switch deben configurarse en la misma sub red. La dirección IP dela computadora de administración debe configurarse manualmente.
Page 12
PDU como resultado de daños por sobretensiones. Para servicio, póngase en contacto con Soporte al Usuario de Tripp Lite en www.tripplite.com/support para remediar el problema o recibir instrucciones acerca de la devolución, reparación o cambio.
Page 13
Características del Producto NSS-G24D2 Panel Frontal: Panel Posterior: Puertos Gigabit Ethernet: Estos 24 puertos RJ45 de par trenzado soportan 10/100/1000 Mbps auto-negociable y detección automática de cross over MDI/MDIX para una capacidad 100% "Conectar y Usar". Nota: No es compatible con aplicaciones de PoE (Energía sobre la Ethernet). LED de Encendido/Apagado: Un LED enciende para indicar que el switch está...
Page 14
PDU como resultado de daños por sobretensiones. Para servicio, póngase en contacto con Soporte al Usuario de Tripp Lite en www.tripplite.com/support para remediar el problema o recibir instrucciones acerca de la devolución, reparación o cambio.
Instalación Instalación en 1U de Rack Instale el switch usando cuatro tornillos para instalación en rack suministrados por el usuario . Antes de la instalación, el usuario debe determinar la capacidad de los tornillos de para instalación en rack para soportar la unidad en el rack.
Page 16
Garantía Limitada por 5 Años TRIPP LITE garantiza durante un período de cinco (5) años desde la fecha de compra inicial que este producto no tiene defectos de materiales ni de mano de obra. La obligación TRIPP LITE bajo esta garantía está limitada a la reparación o reemplazo (A su sola discreción) de cualquier producto defectuoso.
Ce manuel contient des instructions et des avertissements importants devant être respectés au cours de l'installation, de l'utilisation et de l'entreposage de ce produit Tripp Lite. Le non-respect de ces avertissements ou directives peut avoir une incidence sur la garantie.
Accéder à l'interface de configuration de la gestion Après avoir mis le commutateur sous tension pour la première fois, le commutateur de réseau intelligent peut être configuré à l'aide d'un navigateur Web. Pour accéder au commutateur, l'ordinateur de gestion et le commutateur doivent être configurés sous le même sous-réseau. L'adresse IP de l'ordinateur de gestion doit être configurée manuellement.
Page 20
été compromis suite à des dommages causés par une surtension. Pour l'entretien, contacter le service à la clientèle de Tripp Lite à www.tripplite.com/support pour résoudre le problème ou recevoir des instructions concernant le retour, la réparation et l'échange.
Page 21
Caractéristiques du produit NSS-G24D2 Panneau avant : Panneau arrière : Ports Gigabit Ethernet : Ces 24 ports RJ45 à paires torsadées prennent en charge les fonctions auto-négociables 10/100/1000 Mbps et d'auto-détection de croisement MDI/MDIX pour la capacité « prêt à l'emploi ». Remarque : Non compatible avec les applications nécessitant l'alimentation électrique par câble Ethernet (PoE).
Page 22
été compromis suite à des dommages causés par une surtension. Pour l'entretien, contacter le service à la clientèle de Tripp Lite à www.tripplite.com/support pour résoudre le problème ou recevoir des instructions concernant le retour, la réparation et l'échange.
Page 23
Installation Installation à montage en bâti 1U Monter le commutateur en utilisant quatre vis à montage en bâti fournies par l'utilisateur . L'utilisateur doit déterminer l'aptitude des vis pour le montage en bâti à retenir l'appareil au bâti avant montage. Brancher le commutateur à...
TRIPP LITE garantit que ses produits sont exempts de vices de matériaux et de fabrication pendant une période de cinq (5) ans à partir de la date d'achat initiale L'obligation de TRIPP LITE, en vertu de la présente garantie, se limite à la réparation ou au remplacement (à...
