UniView
Parameter Visualization Table
Monitoring and alarm status for various parameters and/or measurements are visualized using the following areas/organs on the screen:
Parameter or Measurement Area Displayed on Visualization Screen
PR Heart
PVi
Vascular
SpHb Vascular
SpMet Vascular
Pi N/A
SpOC N/A
SpO Lung
2
SpCO Lung
RRa Lung
ORi* Lung
PSi** Brain
rSO *** Brain
2
*ORi is currently not available in the U.S.A. and territories relying on FDA market clearance.
** For use with SedLine Sedation Monitor, when connected to Root.
*** For use with O3 Regional Oximeter, when connected to Root.

Changing Patients

The Change Patient option is used to view different patients in the same Masimo System.
To change patients:
1. In the upper-right corner of a layout screen, click the Options menu
Click Change Patient in the drop-down menu.
2.
3. Click OK to confirm leaving the current patient. The Select Patient screen will be displayed.
4. In the Select Patient screen, click the desired patient name. The selected patient's data will be displayed on the Overview screen.
•
For a description of the Overview screen, or to select a different screen layout, see Selecting a Screen Layout on page 14.
•
If a patient is not in the Select Patient screen:
•
The patient may need to be added to the Masimo System. To add a patient to a Masimo System, see the Operator's Manual, Patient
SafetyNet Supplemental Alarm System, Series 5.5.X.X or higher or see Contacting Masimo on page 35.
•
The patient may have been added to a different Masimo System. To disconnect from the current system and login to a different
Masimo System, see Changing Systems on page 27.
