- Page 1 Operator's Manual UniView™...
- Page 3 These operating instructions provide the necessary information for proper operation of all models of UniView. There may be information provided in this manual that is not relevant for your system. General knowledge of pulse oximetry and an understanding of the features and functions of UniView are prerequisites for its proper use.
-
Page 5: Table Of Contents
Chapter 1: Description ..........................................11 System Overview ..........................................11 UniView Overview ..........................................12 Chapter 2: Operation ..........................................13 Opening the UniView Application ....................................... 13 System Login ............................................13 Selecting a Patient ..........................................13 Selecting a Screen Layout ........................................14 Visual Alarms Indicators ........................................20 Alarm Status Visualizer ........................................ -
Page 7: About This Manual
About This Manual This manual explains how to set up and use UniView™. Important safety information relating to general use of UniView appears in this manual. Read and follow any warnings, cautions, and notes presented throughout this manual. The following are explanations of warnings, cautions, and notes. -
Page 9: Product Description, Intended Use And Contraindications
Product Description, Intended Use and Contraindications Product Description UniView is a supplemental display of parameter data and alarm conditions received from Point-of-Care (PoC) devices connected to Masimo Systems (Patient SafetyNet or Iris Gateway). The following PoC devices can display data on UniView via Patient SafetyNet or Iris Gateway Systems: •... -
Page 11: Safety Information, Warnings And Cautions
WARNING: Do not adjust, repair, open, disassemble, or physically modify the UniView host device. Injury to personnel or equipment damage could occur. Return the UniView host device for servicing. WARNING: If UniView host device fails any part of the setup procedures or electrical safety tests, remove the device from operation until qualified service personnel have corrected the situation. -
Page 12: Cleaning And Service Warnings And Cautions
Note: UniView host device installation must be completed by Masimo or an authorized service personnel. Compliance Warnings and Cautions WARNING: Do not attempt to repair or modify any part of UniView host device doing so may void the warranty or the authorization to use the UniView host device. -
Page 13: Chapter 1: Description
Chapter 1: Description System Overview The diagram below describes how UniView receives patient data from PoC devices. The PoC devices, Masimo System, and UniView host device must be configured to the same hospital network. Ref Component Description Point-of-Care (PoC) A device that provides bedside patient monitoring. -
Page 14: Uniview Overview
UniView Overview The image and table below describe UniView features. Ref Feature Description Supplemental visual indicator for alarm conditions of a PoC device connected to a Masimo System. (See Alarm Status Icon on Alarm Status page 20) Icon Note: See the appropriate device operator's manual for setting alarm conditions. -
Page 15: Chapter 2: Operation
Enter the Masimo System username and password credentials. The username and password are provided by your hospital Patient SafetyNet administrator. Click Login. After successful login, the Select Patient screen is displayed. See Selecting a Patient on page 13. If unable to login to the Masimo System, see Troubleshooting on page 31. Selecting a Patient After logging into a Masimo System in UniView, the Select Patient screen displays a patient list. -
Page 16: Selecting A Screen Layout
Chapter 2: Operation Selecting a Screen Layout CAUTION: Always verify the parameter data displayed on the UniView layout screens match the parameter data displayed on the corresponding PoC. If the parameter data is incorrect or not displayed, see Troubleshooting on page 31. - Page 17 (Forehead Right), [6] O3 Regional Oximeter (Forehead Left), [7] Third-Party Monitor, and [8] rainbow. CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter data does not match or does not display on UniView, see Troubleshooting on page 31.
- Page 18 UniView Chapter 2: Operation Ref Window Description Parameter/Waveform Displayed Window Visibility • Displays one capnography device. • Window expands when pump devices • EtCO , FiCO , RR • are disconnected or powered off. Visible when capnography Capnography device is connected •...
- Page 19 Additionally, trend settings [5] for SpHB, PVi, and PR can be adjusted incrementally. See Trend Settings on page 20. CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter data does not match or does not display on UniView, see Troubleshooting on page 31.
- Page 20 See Trend Settings on page 20. CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter data does not match or does not display on UniView, see Troubleshooting on page 31.
- Page 21 Additionally, trend settings [7] for EMG, PSi, and SR can be adjusted incrementally. See Trend Settings on page 20. CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter data does not match or does not display on UniView, see Troubleshooting on page 31.
-
Page 22: Visual Alarms Indicators
CAUTION: If the visual alarms are not displayed or incorrect, see Troubleshooting on page 31. Note: UniView does not generate or manage alarms. The connected devices alarms are a primary for determining that an alarm condition exists. Icon Appearance Description There are currently no active alarms, and no alarms have been silenced. - Page 23 UniView Chapter 2: Operation Parameter Alarms Alarming Parameters Displayed on a Layout Screen If an alarming parameter is viewable on a layout screen [3], the parameter that has exceeded the alarm limit (for example, SpO ) is displayed at the top of the screen [2].
- Page 24 UniView Chapter 2: Operation Alarming Parameters Not Displayed on a Layout Screen If an alarming parameter is not viewable on a layout screen, then the source of the alarming parameter (for example, SEDLINE) and the parameter that has exceeded the alarm limit (for example, PSi) are displayed at the top of the screen [2].
-
Page 25: Alarm Status Visualizer
Successful connection to PoC device • Monitoring: Statuses, notifications, modifiers, notification devices not Yellow assigned to patient, or patient has not been successfully admitted to the Masimo System • Successful connection to PoC device • Monitoring: alarm range Masimo Corporation... -
Page 26: Changing Patients
• The patient may need to be added to the Masimo System. To add a patient to a Masimo System, see the Operator's Manual, Patient SafetyNet Supplemental Alarm System, Series 5.5.X.X or higher or see Contacting Masimo on page 35. -
Page 27: Advanced Features
Click anywhere on the screen to close the Options menu. Adding a System Masimo System(s) must be added to UniView when UniView is opened for the first time. Additional Masimo Systems can be added to UniView after first time use. - Page 28 Editing a System A Masimo System can be edited when system information changes. WARNING: The software settings of the UniView host device should be completed by authorized personnel only. To edit a system in UniView: Go to the login screen by doing one of the following: •...
- Page 29 After successful login, the Select Patient screen displays the system's patient list. See Selecting a Patient on page 13. Deleting a System CAUTION: If a system is accidentally deleted from UniView, only qualified Masimo personnel can add a system. See Contacting Masimo on page 35. To delete a system in UniView: Go to the login screen by doing one of the following: •...
-
Page 31: Chapter 3: Messages
• Username field is empty. obtain the Masimo System username, contact the hospital Patient SafetyNet administrator. • Enter a valid Masimo System password. To obtain Password Required • Password field is empty. the Masimo System password, contact the hospital Patient SafetyNet administrator. -
Page 33: Chapter 4: Troubleshooting
Contact Masimo Service. See Contacting Masimo on connected to a network. page 35. • Ensure both the Masimo System and the PoC device are configured to the same network. • • The Masimo System, PoC, or host device is not Ensure the destination IP address of the PoC device is on the same network. - Page 34 The Masimo System stops working or operates • Contact Masimo Service. See Contacting Masimo on incorrectly. page 35. • The Masimo System and PoC are not on the same network. • Masimo System settings have changed. • Hospital network stops working or is operating incorrectly.
-
Page 35: Chapter 5: Specifications
Chapter 5: Specifications Compatible Masimo Systems The following Masimo Systems are compatible with UniView: System Version Patient SafetyNet v5.5.x.x or higher Iris Gateway v1.5.x.x or higher Symbols Symbols Definition Follow Instructions for use Non-Sterile Not made with natural rubber latex Instructions/Directions for Use/Manuals are available in electronic format @http://www.Masimo.com/TechDocs... -
Page 37: Chapter 6: Warranty Information
Exclusions The warranty does not apply to any non-Masimo branded product or any software, even if packaged with the Product, or any Product that was: (a) not new or in its original packaging when supplied to purchaser; (b) modified without Masimo’s written permission; (c) supplies, devices, or systems external to the Product;... - Page 38 Transfer Restrictions: In no event may Purchaser transfer, assign, rent, lease, sell, or otherwise dispose of the Product or the Software on a temporary basis. Purchaser shall not assign or transfer this License, in whole or in part, by operation of law or otherwise without Masimo's prior written consent;...
-
Page 39: Index
