Product Description - HP Elite x2 G4 Tablet Maintenance And Service Manual

1

Product description

Table 1-1 Product components and their descriptions
Category
Product Name
Processors
Graphics
Panel
Memory
Operating system recovery
storage
Primary storage
Description
HP Elite x2 G4 Tablet
Intel® Core™ processors, quad core
Intel Core i7-8665U (1.9 GHz, turbo up to 4.6 GHz, 8 MB SmartCache, 15 W)
Intel Core i7-8565U (1.8 GHz, turbo up to 4.6 GHz, 8 MB SmartCache, 15 W)
Intel Core i5-8365U (1.6 GHz, turbo up to 4.1 GHz, 6 MB SmartCache, 15 W)
Intel Core i5-8265U (1.6 GHz, turbo up to 3.9 GHz, 6 MB SmartCache, 15 W)
Intel UMA graphics
Intel UHD Graphics 620
13.0 inch, WLED, UWVA, eDP 1.4 + PSR, 72% of NTSC, ultraslim, touch screen
● WUXGA+ (1920 × 1280), antiglare, privacy, 1000 nits
● 3k × 2k (3000 × 2000), BrightView, 450 nits
12.3 inch, WLED, UWVA, 72% of NTSC, eDP 1.4 + PSR, ultraslim
WUXGA+ (1920 × 1280), BrightView, 400 nits
●
Memory soldered onto system board, non-upgradeable, non-removable
LPDDR3 2133
Supports dual-channel memory
Supports up to 16 GB system memory in the following configurations:
16 GB
●
8 GB
●
32 GB eMMC
Supports M.2 2280 solid-state drive (SSD)
128 GB, SATA-3, TLC
256 GB, SATA-3, self-encrypting drive (SED), Opal 2, TLC
256 GB, PCIe
256 GB, PCIe, TLC
512 GB, PCIe, self-encrypting drive (SED), Opal 2, TLC
512 GB, PCIe, value
512 GB, PCIe, TLC
512 GB, PCIe, TLC, FIPS-140-2
1
