Installation, Operating and Servicing
Instructions
Lynx Deck Pizza Oven
LDPO
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 730 ECN 4511
Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Lincat Lynx
Summary of Contents for Lincat Lynx
- Page 1 Installation, Operating and Servicing Instructions Lynx Deck Pizza Oven LDPO Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 730 ECN 4511 Page 1 of 8...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57) -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Fig 2 – (FRONT VIEW) Fig 3 - REAR VIEW A – DOOR HANDLE B – 20 MINS MECHANICAL TIMER C – GREEN NEON (POWER) D – BASE CONTROL THERMOSTAT (1 – 6) E – BASE THERMOSTAT AMBER NEON (HEATING) F –... - Page 6 Only qualified or trained personnel should use this appliance. With all the control knobs in the ‘off/ 12 o’clock’ position, plug the unit into a 13A wall socket and switch on. The green neon (C) located on the fascia will then illuminate indicating power to the appliance.
-
Page 7: Cleaning
CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. Dry with a soft cloth. Occasionally remove the kiln bats and sweep/ vacuum out any debris from the base of the appliance. -
Page 8: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
