Installation, Operating and Servicing
Instructions
Twin Deck Pizza Oven
PO89X
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 110 ECN 3607
Page 1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lincat PO89X
Summary of Contents for Lincat PO89X
- Page 1 Installation, Operating and Servicing Instructions Twin Deck Pizza Oven PO89X Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 110 ECN 3607 Page 1 of 8...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
Under no circumstances should the capillary/bulb be cut open. TECHNICAL DATA Model Height (mm) Width (mm) Depth (mm) Weight (kg) PO89X 81.0 CHECK LIST OF ENCLOSURES Warranty card Instructions manual Refractory bricks x 2 INSTALLATION AND COMMISSIONING This appliance must be earthed. - Page 4 If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance. The fixed wiring insulation must be protected by insulated sleeving having a temperature rating of at least 60 Deg C.
-
Page 5: Operating Instructions
Power Ratings Model Supply 1N~+E (A) Supply 3N~+E (A) PO89X 24.8 L1 7.6 L2 9.6 L3 7.6 OPERATING INSTRUCTIONS Only qualified or trained personnel should use this appliance. Fig 2 Refer to Fig 2 for control functions. The top and bottom ovens have their own set of controls and operate independently. -
Page 6: Cleaning
Set the energy regulator knob (E) to maximum to pre-heat the oven. The amber neon (D) will illuminate. The thermostat neon (C) will go off when the appliance has reached temperature, and cycle as the element maintains the set temperature. When the set temperature is reached, turn the energy regulator down to 3 and then adjust to individual requirements. -
Page 7: Accessories
FE10 Foot HA05 Handle KB21 Refractory brick KN139 Thermostat knob KN270 Timer knob KN92 Energy regulator knob NE37 Amber neon NE38 Green neon SE30 Door seal SW58 Switch TH58 Thermostat TI38 Timer ACCESSORIES Part Number Description POFS Floor stand IS 110 ECN 3607 Page 7 of 8... -
Page 8: Service Information
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
