- Page 1 Installation, Operating and Servicing Instructions Electric Pizza Ovens PO425, PO425-2, PO430, PO430-2, PO630, PO630-2 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 395 ECN 3607 Page 1 of 9...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
The thermostats within this unit contain Potassium-Sodium alloy that react with water and can cause burns. Under no circumstances should the capillary/bulb be cut open. TECHNICAL DATA Model Height (mm) Width (mm) Depth (mm) Weight (kg) PO425 58.0 PO425-2 101.0 PO430 77.0 PO430-2 135.0 1002 PO460 104.0... -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. Install this appliance on a level surface ensuring all vents are unobstructed. Do not site on wooden or Formica surfaces. Keep a gap of 25mm below the base and the surface on which it is situated. -
Page 5: Operating Instructions
12.2, 12.2, 12.2 PO630 31.3 10.4, 10.4, 10.4 PO630-2 14.4 20.8, 20.8, 20.8 The PO425 is fitted with a 13 amp plug. All other units are fitted with a terminal connection labelled as follows: Live 1 Brown Live 2 Black Live 3... - Page 6 Fig 2 Connect the appliance to the electricity supply. With all the control knobs in the ‘Off’ position, turn on at the isolator. The green neon (C) will illuminate. Turn the top element control knob (B) to the desired setting. The amber neon (A) will illuminate.
-
Page 7: Cleaning
Fig 3 CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. Dry with a soft cloth. Occasionally remove the kiln bats and sweep out any debris from the base of the appliance. -
Page 8: Fault Finding
Rotary switch TH101 Control thermostat TH102 Safety thermostat TI38 Timer ACCESSORIES Part Number Description Used on PO425/FS, PO430/FS, PO630/FS Floor stand PO425, PO430, PO630 PO425/SK, PO430/SK, PO630/SK Stacking kit PO425-2, PO430-2, PO630-2 IS 395 ECN 3607 Page 8 of 9... -
Page 9: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
