- Page 1 Operator's Manual HS/VS Label Dispenser Made in Germany...
- Page 2 VS 180+ Edition: 02/2016 - Part No. 9009292 Copyright This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG. The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose demand the previous written authorization by cab.
-
Page 3: Table Of Contents
Table of Contents Introduction ..................4 Product Description .................4 Instructions ..................4 Intended Use ...................5 Safety Instructions ................5 Environment ..................6 Installation ..................7 Device Overview ................7 Unpacking and Setting-up the Device ..........8 Connecting the Device ..............8 2.3.1 Connecting to the Power Supply ..........8 2.3.2 Connecting to the External Control ..........9 Loading Material ................10... -
Page 4: Introduction
Introduction 1.1 Product Description The device is a semiautomatic label dispenser for peeling-off and presenting labels from roll for further manual processing. 1.2 Instructions Important information and instructions in this documentation are designated as follows: Danger! Draws your attention to an exceptionally grave, impending danger to your health or life. -
Page 5: Intended Use
Introduction 1.3 Intended Use • The device is intended exclusively for peeling-off suitable label materials. Any other use or use going beyond this shall be regarded as improper use. The manufacturer/supplier shall not be liable for damage resulting from unauthorized use; the user shall bear the risk alone. •... -
Page 6: Environment
Introduction • There are various warning stickers on the device. They draw your attention to dangers. Warning stickers must therefore not be removed, as then you and other people cannot be aware of dangers and may be injured. • The maximum sound pressure level is less than 70 dB(A). Danger! Danger to life and limb from power supply. -
Page 7: Installation
Installation 2.1 Device Overview 1 Control Panel 2 Brake 3 Roll retainer 4 Margin stop 5 Present sensor 6 Dispense plate 7 Rewinder Fig. 1 Overview HS / HS+ 1 Control Panel 2 Present sensor 3 Roll retainer 4 Margin stop 5 Brake 6 Dispense plate 7 Rewinder... -
Page 8: Unpacking And Setting-Up The Device
Installation 2.2 Unpacking and Setting-up the Device Lift the device out of the box and set it up on a level surface. Check device for damage which may have occurred during transport. Check delivery for completeness. Contents of Delivery: •... -
Page 9: Connecting To The External Control
Installation 2.3.2 Connecting to the External Control for devices with peripheral port only The peripheral port allows to control the device in a network. 1. Check that the device is switched off. 2. Connect the external control to the 9 pin SUB-D connector of the peripheral port (3 / Fig. -
Page 10: Loading Material
Loading Material 3.1 Loading Labels HS / HS+ VS / VS+ Fig. 6 Loading labels 1. Turn ring (7) counterclockwise, so that the arrows points to the symbol and thus release the margin stop (6) from the roll retainer (5). 2. -
Page 11: Adjusting The Present Sensor
Loading Material 3.2 Adjusting the Present Sensor HS / HS+ VS / VS+ Fig. 7 Adjusting the present sensor Reaching the peel position will be recognized by displacement of the feeler (1) by the label to be peeled-off. 1. Release the present sensor (2) by turning the knob (3) counterclockwise. 2. -
Page 12: Operation
Operation 4.1 HS / VS 4.1.1 Operation Switch the device on at the power switch (1 / Fig. 3). The green LED (2) lights up. The first label will immediately be fed to the peel position. Take the label. The next label will be fed to the peel position. -
Page 13: Error Treatment
Operation 4.1.2 Error Treatment If no label is detected by the present sensor within 5 seconds after starting the peel-off operation, the label transport will be stopped and an error will be signalized : The red LED (1) is flashing. •... -
Page 14: Hs+ / Vs
Operation 4.2 HS+ / VS+ 4.2.1 Switching on the Device Attention! Risk of button malfunction. Do not touch the buttons when switching on the device. Switch the device on at the power switch (1 / Fig. 3). The device starts up in the operation mode "Peel-off on demand" Counter and speed setting are in the state of the last switching-off. -
Page 15: Operation Modes
Operation 4.2.2 Operation Modes Check the operation mode by means of the LEDs (2 / 3 / 4). Touch button for changing the operation mode. Automatic Peel-Off After switching in the "Automatic peel-off" mode the first label will immediately be fed to the peel position. -
Page 16: Setting Speed
Operation 4.2.3 Setting Speed Check the chosen speed by means of the LEDs (5 / 6). Touch button for changing the speed setting. 4.2.4 Resetting Counter Touch button for resetting the counter. 4.2.5 Error Treatment If no label is detected by the present sensor within 5 seconds after starting the peel-off operation, the label transport will be stopped and an error will be signalized : The counter display is flashing. -
Page 17: Adjusting The Dispense Plate
Operation 4.2.6 Adjusting the Dispense Plate The label material must run parallel to the chassis, failing this : Loosen screw (2). If the material (1) runs away from the chassis, pull the dispense plate a little out of the guiding (4). ... -
Page 18: Eu Declaration Of Conformity
Person authorised to compile the technical file : Erwin Fascher Am Unterwege 18/20 99610 Sömmerda Signed for, and on behalf of the Manufacturer : Sömmerda, 01.02.2016 cab Produkttechnik Sömmerda Gesellschaft für Computer- und Automationsbausteine mbH Erwin Fascher 99610 Sömmerda Managing Director...
