Using Adsp-Bf506F Ez-Kit Lite - Analog Devices EZ-KIT Lite ADSP-BF506F System Manual

1 USING ADSP-BF506F EZ-KIT
LITE
This chapter provides specific information to assist you with development
of programs for the ADSP-BF506F EZ-KIT Lite evaluation system.
The following topics are covered.
• "Package Contents" on page 1-2
• "Default Configuration" on page 1-3
• "EZ-KIT Lite Installation" on page 1-3
• "EZ-KIT Lite Session Startup" on page 1-5
• "Evaluation License Restrictions" on page 1-7
• "Memory Map" on page 1-7
• "Internal Flash Memory Interface" on page 1-8
• "SPI Flash Memory Interface" on page 1-9
• "Power-On-Self Test" on page 1-9
• "LEDs and Push Buttons" on page 1-10
• "JTAG Interface" on page 1-10
• "Expansion Interface II" on page 1-11
• "VDDINT Programmable Regulator" on page 1-12
• "Power Measurements" on page 1-12
ADSP-BF506F EZ-KIT Lite Evaluation System Manual 1-1
