INTERFACE COMPONENTS
• AX-DSP-X
• AX-DSPX-HYKIA2 harness
• AX-BASSKNOB
• AX-DSP-X harness
• Amplifier bypass harness
APPLICATIONS
Hyundai
Elantra
2012-2015
Veloster
2012-2017
AxxessInterfaces.com
Hyundai/Kia Data Interface with Amplifier
Bypass Harness & DSP 2011-2016
INTERFACE FEATURES
• Designed for SPDIF amplified sound systems
• Includes an amp bypass harness
• Retains BlueLink/UVO voice prompts
• All chimes/voice prompts go through the aftermarket amp
• Adjustable chime level
• Micro-B USB updatable
Kia
Sportage
2011-2016
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
AX-DSPX-HYKIA2
I N S T A L L A T I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Connections ............................................................2
Installation ......................................................... 3-4
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Tone generator
Product Info
REV. 8/16/19 INSTAX-DSPX-HYKIA2
