- Page 1 USER MANUAL I-400SS Please take time to read these instructions before starting to use the scale...
-
Page 2: Table Of Contents
Contents Product Specification Safety Instructions Before Using the Scale Replacing the Battery Operation: Basic Functions Operation: Advanced Functions Error Messages Page 2... -
Page 3: Product Specification
Indicator Display 40mm LCD display with 6 active digits Please note: Marsden’s policy is one of continuous development and therefore we reserve the right to change product specification without notice. Indicator images in this manual are for illustration purposes only. -
Page 4: Safety Instructions
• Air may enter the unit when seals have been replaced. Lift the control lever to the lower position, then move the handle up and down several times. • You can book an accuracy check with the Marsden Service team on 01709 364296. -
Page 5: Before Using The Scale
Page 4 Before using the Scale • Please read these instructions fully before using your I-400SS Indicator. • Ensure the battery is fully charged before first use. Replacing the Battery • Loosen the screws on the battery cover and remove the cover. -
Page 6: Operation: Basic Functions
Page 5 Operation: Basic Functions Switching the Scale on/off Press PRINT/ON/OFF to power-on the scale. When the scale shows 0.0 it is ready for weighing. To switch the scale off, press and hold PRINT/ON/OFF for three seconds. The scale will now power down. Setting the Scale to Zero If at any time the reading shows anything other than 0.0 when there is... -
Page 7: Operation: Advanced Functions
Page 6 Operation: Advanced Functions Hold Function With the scale switched on, add an item to the base. Press HOLD once. The scale will lock onto and stabilise the weight reading for the item. The reading will remain displayed after the item is removed. Press HOLD again to disable the Hold function and return the scale to 0.000. - Page 8 Place the item you wish to deduct the weight of (such as a pallet or empty box) on the scale and press TARE. Page 7 The scale will show a minus reading. Weigh as normal and the negative weight reading will be deducted from the total weight.
- Page 9 Once you have finished weighing, press TARE again to remove the tare value and return the scale to 0.0. Switching Between Kg and lb To switch the weight reading between kg and lb, press LB/KG. The LCD panel will indicate whether the reading is showing in kg or lb as shown on the left.
-
Page 10: Error Messages
Press PRINT/ON/OFF, and F3.1 should appear on the screen. Press PRINT/ON/OFF again. Use LG/KG, GROSS, TARE and ZERO as arrow keys to select the power-off delay (up to 60 mins). Press PRINT/ON/OFF once and HOLD twice to set the time out period and return to normal weighing mode. - Page 11 AD initialization error Switch off the scale and restart. If the error occurs again, contact your dealer/Marsden NOTE: If the scale shows any error message other than those listed above, please contact Marsden on 01709 364296. Page 10...
- Page 12 Tel: 01709 364296 / 0800 169 2775 Fax: 01709 364293 E-mail: sales@marsdengroup.co.uk Manufacturing and Distribution: Unit 7, Centurion Business Park, Coggin Mill Way, Rotherham, S60 1FB Head Office: Unit 1, Genesis Business Park, Sheffield Road, Rotherham S60 1DX www.marsden-weighing.co.uk...
