Installing an AGP Card in the Silicon Graphics® 230, 330, and 550 Visual Workstations
•
Place the two tabs onto the lower chassis rail.
•
Slide the side panel toward the rear of the system, until the rear tab hits the rear
of the chassis and the side panel cannot be moved any farther. Figure 4
illustrates the procedure.
1
2
2
1
Placing Side Panel onto Lower Chassis Rail
Figure 4
•
Push the upper side of the side panel toward the chassis.
•
Gently lift the side panel and push it against the chassis.
•
Slide the side panel towards the front of the chassis until it fits into place. The
procedure is illustrated in Figure 5.
Side panel tabs
5
