When the lights come on, they should enter program #1 (Voodoo Lounge), and be synchronized.

Programs

When in Universal ColorLogic mode (default), the ColorLogic light has the capability to display 17 dif-
ferent programs; 10 fixed colors and 7 color-changing shows. These programs are advanced using
power-cycling (quickly powering the lights on, then off, then back on). The programs are listed below:
1. Show-Voodoo Lounge
2. Fixed-Deep Blue Sea
3. Fixed-Royal Blue
4. Fixed-Afternoon Skies
5. Fixed-Aqua Green
6. Fixed-Emerald
7. Fixed-Cloud White
8. Fixed-Warm Red
9. Fixed-Flamingo
Refer to the included color card as a quick reference to the available programs.
Omni Direct (Lights built after June, 2018)
LACUS11xxx and LYCUS11xxx 1.5" ColorLogic lights must be configured and controlled by a Hay-
ward OmniLogic or OmniHub pool control to use Omni Direct mode. This mode offers some unique
colors as well as speed and brightness control. The programs are listed below.
1. Show-Voodoo Lounge
2. Fixed-Deep Blue Sea
3. Fixed-Royal Blue
4. Fixed-Afternoon Skies
5. Fixed-Aqua Green
6. Fixed-Emerald
7. Fixed-Cloud White
8. Fixed-Warm Red
9. Fixed-Flamingo
10. Fixed-Vivid Violet
11. Fixed-Sangria
12. Show-Twilight
13. Show-Tranquility
14. Show-Gemstone
Refer to the OmniLogic or OmniHub manuals for Omni Direct configuration and operation information.

Networking

Using a ColorLogic modem AQL-COLOR-MODHV and Coupler LKBUN1000, owners of Pro Logic
automation controls can network their LACUN11xxx and LYCUN11xxx model lights allowing them
to fully control the color, speed, motion and brightness of preset light shows. If the lights will be
networked, refer to the AQL-COLOR-MODHV ColorLogic Network module for operation instructions.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
10. Fixed-Vivid Violet
11. Fixed-Sangria
12. Show-Twilight
13. Show-Tranquility
14. Show-Gemstone
15. Show-USA
16. Show-Mardi Gras
17. Show-Cool Cabaret
15. Show-USA
16. Show-Mardi Gras
17. Show-Cool Cabaret
18. Fixed-Yellow
19. Fixed-Orange
20. Fixed-Gold
21. Fixed-Mint
22. Fixed-Teal
23. Fixed-Burnt Orange
24. Fixed-Pure White
25. Fixed-Crisp White
26. Fixed-Warm White
27. Fixed-Bright Yellow
